Network Switch PLANET IPOE-171-60W

The PLANET IPOE-171-60W is an industrial single-port 802.3bt Power over Ethernet injector that supplies up to 60 W over Ethernet cabling while providing two 100M/1G/2.5G/5GBASE-T RJ45 copper interfaces for high-speed data transmission. Designed for higher-power network devices, it supports lighting, all-in-one touch PCs, remote digital signage displays and other PDs that require elevated power for normal operation. The IPOE-171-60W delivers both Ethernet data and DC power over twisted-pair cables and pairs with the IPOE-173S splitter to separate data and power into selectable 12 V or 24 V DC outputs at distances up to 100 m.

Advantages

The injector sources up to 60 W using all four pairs of standard Cat.5e/6 cabling, supports backward compatibility with 802.3af/at devices, and offers two DC redundant power inputs and multiple front-panel LEDs for power input, fault and real-time PoE power usage monitoring. Its compact IP30 metal housing supports DIN-rail or wall mounting and its operating range of -40 to 75 °C ensures stable performance in demanding industrial environments. Legacy and Force modes increase compatibility with PDs that do not fully follow IEEE 802.3at/bt detection protocols.

Suitable for

• Industrial and outdoor lighting systems requiring PoE power
• All-in-one touch PCs and kiosks
• Remote digital signage and displays
• High-power IP cameras and wireless access points

Key specifications

• Model: PLANET IPOE-171-60W
• PoE standard: IEEE 802.3bt (backward compatible with 802.3at/af)
• Maximum PoE output: up to 60 W over 4-pair Ethernet
• Data ports: 2 x RJ45 (100M/1G/2.5G/5GBASE-T)
• DC input voltage: 48–56 V (two redundant DC inputs)
• Operating temperature: -40 to 75 °C
• Housing: IP30 metal, wall or DIN-rail mountable
• Weight: 0.43 kg

How to use

Install the IPOE-171-60W on a DIN rail or wall-mount bracket, connect a compatible DC power source to the redundant DC input terminals, and plug the Ethernet cable from your network switch into the Ethernet port. Connect the Ethernet + DC port to the powered device or to an IPOE-173S splitter if the PD requires separate DC outputs (12 V/24 V). No software configuration is required; the injector performs plug-and-play delivery of data and PoE power up to 100 m over standard Cat.5e/6 cabling.

Recommendations

Use quality Cat.5e or Cat.6 cables for distances up to 100 m and confirm the PD power requirements before deployment. Enable Legacy or Force modes only when connecting devices that fail IEEE detection tests, and ensure redundant DC inputs are wired to separate power sources for improved availability in industrial installations.
