DIGITUS Patch panel CAT6 8-ports Shielded Black 10in

DIGITUS Patch panel CAT6 8-ports Shielded Black 10in
DIGITUS Patch panel CAT6 8-ports Shielded Black 10in
DIGITUS Patch panel CAT6 8-ports Shielded Black 10in
DIGITUS Patch panel CAT6 8-ports Shielded Black 10in
DIGITUS Patch panel CAT6 8-ports Shielded Black 10in
DIGITUS Patch panel CAT6 8-ports Shielded Black 10in
DIGITUS Patch panel CAT6 8-ports Shielded Black 10in
DIGITUS Patch panel CAT6 8-ports Shielded Black 10in
DIGITUS Patch panel CAT6 8-ports Shielded Black 10in
DIGITUS Patch panel CAT6 8-ports Shielded Black 10in
DIGITUS Patch panel CAT6 8-ports Shielded Black 10in
DIGITUS Patch panel CAT6 8-ports Shielded Black 10in
DIGITUS Patch panel CAT6 8-ports Shielded Black 10in
DIGITUS Patch panel CAT6 8-ports Shielded Black 10in
DIGITUS Patch panel CAT6 8-ports Shielded Black 10in
DIGITUS Patch panel CAT6 8-ports Shielded Black 10in
DIGITUS Patch panel CAT6 8-ports Shielded Black 10in
DIGITUS Patch panel CAT6 8-ports Shielded Black 10in
R544
Future-oriented standards and high-end quality for your network.- Easy wire installation possible due to color coded LSA strips- Shielding provides optimized performances- Compact 10" design with 8x RJ45 portsThe CAT 6 Patch Panels for 254 mm (10") rack mount from DIGITUS® are manufactured with Link... Read More
Stock 1 Code 120242 Brand DIGITUS Model DN-91608S Warranty 2 Years

Shipping & Returns

Estimated delivery Thursday, October 1
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

Future-oriented standards and high-end quality for your network.

- Easy wire installation possible due to color coded LSA strips
- Shielding provides optimized performances
- Compact 10" design with 8x RJ45 ports

The CAT 6 Patch Panels for 254 mm (10") rack mount from DIGITUS® are manufactured with Link Performance Class E, for up to 250 MHz, ISO/IEC 11801 and EN 50173. Cable installation takes place via LSA strips which are color coded acc. EIA/TIA 568B. The housing consists of galvanized, cold-rolled steel, acc. EN1.4301, UNS S30400, AISI 304 and LMSAD110.

Key Highlights
  • Area of application: Up to 250 MHz, 1GBase-T
  • Norms: ISO/IEC 11801 3rd Ed., EN 50173-1, EIA/TIA 568-C
  • General properties:
  • Suitable for 254 mm (10") cabinet mounting
  • RJ45 female, 8P8C
  • Cable installation via LSA strips, color coded according to EIA/TIA 568 A & B
  • Cable fixing with smart cable ties
  • Integrated dust cover
  • Central ground connection
  • 360° shield coverage
  • Mechanical properties:
  • Housing material: 1.5 mm galvanic cold rolled steel, acc. to EN1.4301, UNS S30400, AISI 304 and LMSAD110
  • RJ45 female material: ABS UL 94V-0
  • RJ45 female contact: Tinned phosphor bronze, 0.5 μ gold-plated contact
  • RJ45 shielding: Tinned bronze
  • LSA termination clamp: Krone LSA+, UL 94V-2, zinc plated phosphor bronze
  • Ground wire: Not included
  • Conductor plate: FR4, UL 94V-0
  • Physical properties:
  • Insertion force: 30N max. (IEC 60603-7-5)
  • Retention strength: 7.7 kg between jack and plug
  • Operation temperature: -20° C to +70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA/EIA 568 C)
  • Mating cycles female: > 750 acc. to ISO/IEC 11801, IEC 60603-7-5
  • Clamp: > 200 acc. to ISO/IEC 11801, IEC 60603-7-5
  • IDC wire size: 22 – 26 AWG solid and stranded conductor
  • Insulation resistance: > 500 MOhm
  • Contact resistance: < 20 MilliOhm
  • Dielectric strength: 1000 VDC (Contact/Contact), 1500 VDC (Contact/Ground)
Specifications
Certification
UL
Connector(s)
RJ-45
Country of origin
China
Harmonized System (HS) code
85371098
Mounting
Rack mounting
Package depth
280 mm
Package volume
3024 cm³
Package weight
1.5 kg
Package width
180 mm
Ports quantity
8
Product colour
Black
Rack capacity
1U
UK Trade Tariff code
85369010

Leaflet

Open Leaflet
