ATEN 16-Port USB - PS/2 VGA KVM Switch with USB Peripheral port

ATEN 16-Port USB - PS/2 VGA KVM Switch with USB Peripheral port
ATEN 16-Port USB - PS/2 VGA KVM Switch with USB Peripheral port
ATEN 16-Port USB - PS/2 VGA KVM Switch with USB Peripheral port
ATEN 16-Port USB - PS/2 VGA KVM Switch with USB Peripheral port
ATEN 16-Port USB - PS/2 VGA KVM Switch with USB Peripheral port
ATEN 16-Port USB - PS/2 VGA KVM Switch with USB Peripheral port
R7,751
The CS1716A KVM switch is a control unit that allows access to multiple computers from a single PS/2 or USB console (keyboard, mouse, and monitor). A single CS1716A can control up to 16 computers. As many as 31 additional switches can be daisy-chained to each other, so that up to 512 computers can a... Read More
Stock 4 Code 299842 Brand ATEN Model CS1716A-AT-G Warranty 2 Years

Shipping & Returns

Estimated delivery Tuesday, October 6
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival
The CS1716A KVM switch is a control unit that allows access to multiple computers from a single PS/2 or USB console (keyboard, mouse, and monitor). A single CS1716A can control up to 16 computers. As many as 31 additional switches can be daisy-chained to each other, so that up to 512 computers can all be controlled from a single keyboard-monitor-mouse console. Additionally, a front panel USB port is available for each computer to access any peripherals connected to it on a one-at-a-time basis.
1x KVM Switch with Standard Rack Mounting Kit
1x 2L-5202P PS/2 KVM Cable
1x 2L-5202U USB KVM Cable
1x LIN5-27X6-U21G Console Cable
1x Firmware Upgrade Cable
1x Foot Pad Set(4 PCS)
1x 0AD8-1605-24M1 Power Adapter
1x User Instructions

ATEN 16-Port USB - PS/2 VGA KVM Switch with USB Peripheral port. Keyboard port type: USB, PS/2, Mouse port type: USB, PS/2, Video port type: VGA. HD type: QXGA, Maximum resolution: 2048 x 1536 pixels, Scan interval: 1,255 s. Product colour: Black, Rack capacity: 1U, Housing material: Metal. Power source: DC, Input voltage: 5.3 V, Power consumption (typical): 6.6 W. Compliance certificates: RoHS

Key Highlights
  • Superior video quality - up to 2048 x 1536; DDC2B
  • One USB-PS/2 console controls up to 16 computers; Daisy-chain up to 31 additional units - control up to 512 computers from a single console
  • Broadcast Mode - operation simultaneously performed on all selected computers... etc
  • Video DynaSync™ - stores the console monitor EDID to optimize display resolution
  • Rack mounting 1U Black
  • Number of computers controlled: 512
  • Keyboard port type: USB, PS/2 Mouse port type: USB, PS/2 Video port type: VGA
  • QXGA 2048 x 1536 pixels
  • Housing material: Metal
  • Hot keys
  • DC 6.6 W
Specifications
AC adapter included
Yes
Built-in display
No
Cables included
KVM
Compliance certificates
RoHS
Console ports
USB A, VGA (D-Sub)
Console USB ports quantity
1
Daisy chain
Yes
DC-in jack
Yes
DDC2B support
Yes
Depth
159.9 mm
Firmware upgradeable
Yes
Harmonized System (HS) code
85176200
HD type
QXGA
Height
44 mm
Hot keys
Yes
Hot-Plug support
Yes
Housing material
Metal
Input voltage
5.3 V
Keyboard port type
USB, PS/2
LED indicators
Yes
Linux operating systems supported
Yes
Mac operating systems supported
Yes
Master (outer) case gross weight
12.6 kg
Master (outer) case height
258 mm
Master (outer) case length
565 mm
Master (outer) case net weight
10.8 kg
Master (outer) case width
375 mm
Maximum resolution
2048 x 1536 pixels
Mouse port type
USB, PS/2
Number of computers controlled
512
On Screen Display (OSD)
Yes
Operating relative humidity (H-H)
0 - 80%
Operating temperature (T-T)
0 - 50 °C
Package depth
540 mm
Package height
233 mm
Package weight
4 kg
Package width
116 mm
Power consumption (typical)
6.6 W
Power source
DC
Product colour
Black
Products per master (outer) case
3 pc(s)
Push button
Yes
Quick installation guide
Yes
Rack capacity
1U
Rack mount kit
Yes
Rack mounting
Yes
Scan interval
1,255 s
Storage temperature (T-T)
-20 - 60 °C
VGA (D-Sub) ports quantity
17
Video port type
VGA
Weight
3.61 kg
Width
437.2 mm
Windows operating systems supported
Yes
