ATEN CS1762A KVM switch Black

Name: ATEN CS1762A KVM switch Black
Brand: ATEN
SKU: 2395168
Price: 3320.00 ZAR
Availability: InStock

ATEN CS1762A KVM switch Black

R3,320

+R11 store credit

PDF

Qty

Add to Cart

Add to Wish List Compare this Product

PDF

Stock 13 Code 2395168 Model CS1762A Warranty 2 Years

DepartmentPeripherals & Input Devices

CategoryKVM Switches

BrandATEN

Shipping & Returns

Estimated delivery Thursday, November 26

You will be kept updated through our detailed tracking system

Payment options

EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

Ask a question – the AI assistant answers instantly.

html .tab-container.product_extra.product_tabs.product_tabs-default:not(.dn-product-info-ready)>*{opacity:1!important;visibility:visible!important;pointer-events:auto!important}html .tab-container.product_extra.product_tabs.product_tabs-default:not(.dn-product-info-ready)::before,html .tab-container.product_extra.product_tabs.product_tabs-default:not(.dn-product-info-ready)::after{display:none!important}html .tab-container.product_extra.product_tabs.product_tabs-default:not(.dn-product-info-ready){min-height:0!important}

Description

The CubiQ™ CS1762A USB 2.0 DVI KVMP™ Switch charts a revolutionary new direction in KVM (Keyboard, Video, Mouse) switch functionality by combining a 2 port KVM switch with a 2 port USB 2.0 hub at the same time as it provides an interface for a digital monitor (DVI).

In addition, the CS1762A comes with ATEN's new Video DynaSync™ technology, which optimizes display resolution, and power on detection, which means if one computer is powered off, the CS1762A will automatically switch to the next powered-on computer.
As a KVM switch, it allows users to access two computers from a single USB keyboard, USB mouse, and monitor console. As a USB 2.0 hub, it permits each computer to access any peripherals connected to the hub on a 'one computer at a time' basis.

ATEN CS1762A. Keyboard port type: USB, Mouse port type: USB, Video port type: DVI-I. HD type: WUXGA, Maximum resolution: 1920 x 1200 pixels, Scan interval: 1,99 s. Product colour: Black, Housing material: Metal. Power source: DC, Input voltage: 5.3 V, Power consumption (typical): 9 W. Compliance certificates: RoHS

Key Highlights

One USB console controls two DVI computers and two additional USB 2.0 devices
2-port USB 2.0 hub built in
Fully compliant with the USB 2.0 specification
Computer selection via front panel pushbuttons, hotkeys, and mouse
Audio enabled – full bass response provides a rich experience for 2.1 channel surround sound systems
Multiplatform support – Windows, Linux, Mac, and Sun
Supports widescreen resolutions
Superior video quality – 1920 x 1200
Independent switching of KVM, USB, and Audio focus
DVI digital and analog monitor support – fully compliant with the DVI specifications
HDCP compatible
Video DynaSync™ – exclusive ATEN technology optimizes display resolution and eliminates boot-up display problems
Power on detection – if one computer is powered off, the switch will automatically switch to the next powered-on computer
Console mouse port emulation/bypass feature supports most mouse drivers and multifunction mice
Complete keyboard emulation for error-free booting
Mac/Sun keyboard support and emulation*
Multilingual keyboard mapping – supports English, Japanese, and French keyboards
Auto Scan Mode for monitoring all computers
Firmware upgradable
* 1. PC keyboard combinations emulate Mac/Sun keyboards
2. Mac/Sun keyboards only work with their own computer
Black
Number of computers controlled: 2
Keyboard port type: USB Mouse port type: USB Video port type: DVI-I
WUXGA 1920 x 1200 pixels
Housing material: Metal
Hot keys
DC 9 W

Specifications

AC adapter included

Yes

Audio connections

Yes

Built-in display

Cables included

KVM

Compliance certificates

RoHS

Console ports

3.5mm headphone, 3.5mm mic, DVI-I, USB A

DC-in jack

Yes

Depth

88 mm

DVI-I ports quantity

Harmonized System (HS) code

85176200

HD type

WUXGA

HDCP

Yes

Headphone outputs

Height

55.5 mm

Hot keys

Yes

Housing material

Metal

Input voltage

5.3 V

Keyboard port type

USB

LED indicators

Yes

Linux operating systems supported

Yes

Mac operating systems supported

Yes

Manual

Yes

Maximum resolution

1920 x 1200 pixels

Mouse port type

USB

Number of computers controlled

Number of microphone inputs

On Screen Display (OSD)

Operating relative humidity (H-H)

0 - 80%

Operating temperature (T-T)

0 - 50 °C

Other operating systems supported

Yes

Power consumption (typical)

9 W

Power on detection

Yes

Power source

Product colour

Black

Push button

Yes

Quick installation guide

Yes

Rack mounting

Scan interval

1,99 s

Storage temperature (T-T)

-20 - 60 °C

USB connector type

USB Type-A, USB Type-B

USB hub

Yes

USB version

2.0

Video port type

DVI-I

Weight

730 g

Width

210 mm

Windows operating systems supported

Yes
