Managed L3 Gigabit Ethernet Switch PLANET IGS-5225-8T2S2X

The PLANET IGS-5225-8T2S2X is an industrial managed L3 Gigabit Ethernet switch in a rugged IP30 aluminium case. It provides 8 10/100/1000 Mbps RJ-45 copper ports, 2 100/1000/2500BASE-X SFP ports and 2 10G SFP+ ports, with a non-blocking switching capacity up to 66 Gbps and a MAC address table of 32,000 entries. The switch supports static Layer 3 routing, various Layer 2 features and industry networking standards, accepts 12–48 V DC input, and can be mounted on a DIN rail or wall for installation in industrial and demanding environments.

Advantages

The IGS-5225-8T2S2X offers 10 Gbps uplink capacity and flexible SFP/SFP+ port options for extending networks over different distances and speeds. Its hardened design supports operation from -40 to 75 °C and features redundant power inputs, rapid ring recovery (ITU-T G.8032 ERPS) and multiple redundancy protocols for high availability. Security features include DHCP Snooping, IP Source Guard, ARP inspection, 802.1x authentication, RADIUS/TACACS+, and SNMPv3. Management is available via console, web GUI, Telnet and SNMP.

Suitable for

• Industrial automation and factory floor networks
• Surveillance systems and video backhaul requiring fast recovery
• Carrier Ethernet and telecom edge applications
• Enterprise aggregation with 10G uplinks to servers or core switches
• SCADA, HMI and other Modbus TCP/IP integrated systems

Key specifications

• Ports: 8 x 10/100/1000 RJ-45, 2 x 100/1000/2500BASE-X SFP, 2 x 10G SFP+
• Switching capacity: 66 Gbps
• MAC table: 32,000 entries
• Layer support: Layer 2+ with static Layer 3 routing, IPv4/IPv6 VLAN routing
• Redundancy & protocols: ITU-T G.8032 ERPS, MSTP (802.1s), RSTP, LACP
• Security: DHCP Snooping, IP Source Guard, ARP Inspection, 802.1x, RADIUS, TACACS+, SNMPv3
• Diagnostics: SFP-DDM support
• Management: Web GUI, CLI (console/Telnet), SNMP v3
• Power & mounting: 12–48 V DC input, redundant power, DIN-rail or wall mount
• Operating temperature: -40 to 75 °C

How to use

Install the switch on a DIN rail or mount it to the wall and connect DC power within the specified 12–48 V range. Populate SFP/SFP+ slots with suitable transceivers according to required link speed and distance. Configure basic network settings and VLANs via the web GUI or console, set up redundancy protocols (ERPS/MSTP) for ring topologies, and enable security features such as DHCP Snooping, IP Source Guard and 802.1x. For integration with automation systems, enable Modbus TCP/IP to allow remote monitoring of port and device status.

Recommendations

Use quality, compatible SFP/SFP+ transceivers for reliable 10G links, enable redundant power inputs and ring protection in critical deployments, and keep firmware and security protocol kernels (SSH/SSL) updated. Monitor SFP parameters via DDM and configure SNMP or SMTP alerts to receive fast notification of faults or link events.
