DC/DC Converter ATTE ASUC-100-480-OF 100W 48V Input 12V Output DIN Rail

The ATTE ASUC-100-480-OF is a high-performance DC/DC converter designed for industrial applications requiring reliable power conversion. With a nominal input of 48 VDC and a wide input range of 36-72 VDC, it delivers a stable 12 VDC output at up to 8.3 A, providing 100 W of power. Its compact DIN rail mount design makes it ideal for control cabinets and automation systems.

Advantages

This converter offers high efficiency up to 92%, reducing energy loss and heat generation. It features comprehensive protection including short circuit, overload, overvoltage, and overtemperature, ensuring safe operation in demanding environments. The free air convection cooling eliminates the need for fans, enhancing reliability and reducing maintenance.

Suitable for

• Industrial automation and control systems
• Telecommunications equipment
• Building management systems
• Any application requiring 48V to 12V conversion with DIN rail mounting

Key specifications

• Input Voltage: 36-72 VDC (nominal 48 VDC)
• Output Voltage: 12 VDC
• Output Current: 8.3 A
• Output Power: 100 W
• Efficiency: Up to 92%
• Isolation Voltage: 1.5 kVAC (Input to Output)
• Protection: Short Circuit, Overload, Overvoltage, Overtemperature
• Operating Temperature: -25°C to +70°C
• Cooling: Free Air Convection
• Mounting: DIN Rail (TS-35/7.5 or TS-35/15)
• Connectors: Screw Terminals (Input and Output)
• Ripple & Noise: <100 mVp-p
• Line Regulation: <0.5%
• Load Regulation: <1%
• Humidity: 20-90% RH non-condensing
• Certifications: CE

Recommendations

For optimal performance, ensure proper ventilation and mounting on a standard DIN rail. This converter is a reliable choice for industrial power distribution and can be used as a direct replacement for similar models.
