ATTE IPUPS-8-20-R5U0 10-Port Rackmount PoE Switch with 8 PoE Ports and 2 Gigabit Uplinks, 120W Budget

Powering multiple IP cameras often means wrestling with a tangle of power adapters and insufficient network ports. The ATTE IPUPS-8-20-R5U0 eliminates that clutter by combining data and power delivery over a single Ethernet cable to up to eight cameras. Built for surveillance deployments, this unmanaged rackmount switch provides eight 10/100 Mbps PoE ports and two Gigabit uplink ports, all in a compact 1U form factor.

Who is it for

This switch is ideal for small to medium-sized IP camera installations where rack space is limited but reliability is critical. It suits integrators, IT administrators, and security professionals who need a straightforward, plug-and-play PoE solution without complex configuration.

Main features

• 8 PoE ports (10/100 Mbps) compliant with IEEE 802.3af/at, delivering up to 20W per port
• 2 Gigabit uplink ports (10/100/1000 Mbps) for high-speed backbone connectivity
• Total PoE power budget of 120W, enough for multiple cameras and other PoE devices
• Unmanaged operation – no setup required, just connect and power
• Rackmount design (1U) with included mounting brackets for tidy installations
• Store-and-forward switching with auto MDI/MDIX on all ports
• Robust metal housing for durability in equipment rooms

Specifications

• Total Ethernet ports: 10 (8 PoE + 2 uplink)
• PoE standard: IEEE 802.3af/at
• Switching capacity: 5.6 Gbps
• Forwarding rate: 4.16 Mpps
• MAC address table: 2K entries
• Jumbo frame support: 1536 bytes
• Power input: 100-240V AC, 50/60Hz (internal power supply)
• Operating temperature: -10°C to 50°C
• Dimensions (W x D x H): 220 x 150 x 44 mm
• Weight: 1.2 kg

Tips

To maximize the PoE budget, calculate the power draw of each connected camera. The switch can supply up to 20W per port, but the total across all ports must not exceed 120W. Use Cat5e or better cabling for reliable PoE delivery, especially over longer runs.
