PLANET TECHNOLOGY CORP. IGS-5225-8P4X Industrial 8-Port 10/100/1000T 802.3bt PoE + 4-Port 10G SFP+ Ethernet Switch (360W PoE Budget, PoE Usage LED, -40~75°C, Dual 48~54V DC)

The PLANET TECHNOLOGY CORP. IGS-5225-8P4X is a rugged industrial managed Ethernet switch designed for demanding environments. It features 8 Gigabit PoE ports compliant with IEEE 802.3bt Ultra PoE (up to 95W per port) and 4 10G SFP+ uplink ports, providing a total PoE budget of 360W. With an IP30 metal housing, dual redundant DC power inputs, and an extended operating temperature range of -40 to 75°C, this switch ensures reliable operation in harsh conditions. It supports Layer 3 static routing, VLAN routing, and advanced PoE management features such as PoE schedule, PD Alive Check, and power budget control.

Advantages

High power PoE++ support (up to 95W per port) enables powering of high-demand devices like PTZ cameras and wireless access points. The 10G SFP+ uplinks provide high-speed backbone connectivity. Industrial-grade design with IP30 rating and wide temperature tolerance ensures stable performance in factories, outdoor enclosures, and other extreme environments. Dual redundant power inputs enhance reliability.

Suitable for

• Industrial automation networks
• Surveillance systems with high-power PoE devices
• Outdoor and harsh environment deployments
• Enterprise edge networks requiring high-speed uplinks

Key specifications

• 8 x 10/100/1000BASE-T RJ45 PoE ports (802.3bt/at/af)
• 4 x 10GBASE-X SFP+ slots (backward compatible with 1G SFP)
• Total PoE budget: 360W
• Switching capacity: 96 Gbps
• Forwarding rate: 71.42 Mpps
• MAC address table: 16K entries
• Jumbo frame support: 10K bytes
• Operating temperature: -40 to 75°C
• Power input: Dual redundant 48~54V DC
• Enclosure: IP30 metal case
• Mounting: DIN-rail and wall-mount
• Layer 3 features: Static routing, VLAN routing
• PoE management: PoE Usage LED, PoE schedule, PD Alive Check, power budget control
• ESD protection: 6KV DC

Recommendations

For optimal performance, use high-quality SFP+ modules and ensure adequate ventilation. The switch supports 1G SFP modules for backward compatibility. Consider using a UPS for uninterrupted power supply.
