DC/DC Converter ATTE ASUC-100-AD0-OF 100W 12V 8.3A DIN Rail

The ATTE ASUC-100-AD0-OF is a high-efficiency DC/DC converter designed for industrial applications. It converts a wide input voltage range of 10-30V DC to a stable 12V DC output, delivering up to 100W of power. With its compact DIN rail mountable design and comprehensive protection features, it is ideal for use in automation, control systems, and other demanding environments.

Advantages

This converter offers exceptional reliability and performance. Its fanless convection cooling ensures silent operation and long service life. The wide input voltage range provides flexibility for various power sources, while the high efficiency (>90%) reduces energy waste and heat generation. Built-in protections against overload, short circuit, overvoltage, and reverse polarity safeguard both the converter and connected equipment.

Suitable for

• Industrial automation and control systems
• Building management and security systems
• Telecommunications equipment
• Embedded systems and IoT devices
• Any application requiring a stable 12V DC supply from a variable DC source

Key specifications

• Input Voltage: 10-30V DC
• Output Voltage: 12V DC
• Output Current: 8.3A
• Output Power: 100W
• Efficiency: >90%
• Input/Output Connector: Screw Terminals
• Protection: Overload, Short Circuit, Overvoltage, Reverse Polarity
• Operating Temperature: -25°C to +55°C
• Cooling: Convection (Fanless)
• Mounting: DIN Rail / Screw Mount
• Enclosure Rating: IP20
• Isolation Voltage: 1.5 kV (Input to Output)
• Ripple & Noise: <100mVp-p
• Line Regulation: ±0.5%
• Load Regulation: ±1%
• Number of Outputs: 1
• Series: ASUC Series
• Certifications: CE

Recommendations

For optimal performance, ensure adequate ventilation around the converter. Use appropriate gauge wire for screw terminals and observe polarity. This device is not suitable for outdoor use without additional enclosure protection.
