ASRock Motherboard TRX50 Ws AMD TRX50 Ryzen 4 X DDR5 7.1ch HD Audio EATX

ASRock Motherboard TRX50 Ws AMD TRX50 Ryzen 4 X DDR5 7.1ch HD Audio EATX
ASRock Motherboard TRX50 Ws AMD TRX50 Ryzen 4 X DDR5 7.1ch HD Audio EATX
ASRock Motherboard TRX50 Ws AMD TRX50 Ryzen 4 X DDR5 7.1ch HD Audio EATX
ASRock Motherboard TRX50 Ws AMD TRX50 Ryzen 4 X DDR5 7.1ch HD Audio EATX
ASRock Motherboard TRX50 Ws AMD TRX50 Ryzen 4 X DDR5 7.1ch HD Audio EATX
36 mo.
ASRock Motherboard TRX50 Ws AMD TRX50 Ryzen 4 X DDR5 7.1ch HD Audio EATX
ASRock Motherboard TRX50 Ws AMD TRX50 Ryzen 4 X DDR5 7.1ch HD Audio EATX
ASRock Motherboard TRX50 Ws AMD TRX50 Ryzen 4 X DDR5 7.1ch HD Audio EATX
ASRock Motherboard TRX50 Ws AMD TRX50 Ryzen 4 X DDR5 7.1ch HD Audio EATX
ASRock Motherboard TRX50 Ws AMD TRX50 Ryzen 4 X DDR5 7.1ch HD Audio EATX
R11,883
The ASRock TRX50 WS is a high-performance EATX motherboard engineered for AMD Ryzen Threadripper 1000 Series processors, utilizing the Socket sTR5 and AMD TRX50 chipset. It supports DDR5-SDRAM memory via DIMM slots, with a maximum capacity of 1 TB, and delivers robust connectivity and storage option... Read More
Stock 1 Code 308037 Brand ASROCK Model 90-MXBN40-A0UAYZ Warranty 3 Years

Shipping & Returns

Estimated delivery Thursday, October 8
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

The ASRock TRX50 WS is a high-performance EATX motherboard engineered for AMD Ryzen Threadripper 1000 Series processors, utilizing the Socket sTR5 and AMD TRX50 chipset. It supports DDR5-SDRAM memory via DIMM slots, with a maximum capacity of 1 TB, and delivers robust connectivity and storage options for demanding workstation builds.

Key features

  • Supports AMD Ryzen Threadripper 1000 Series processors on Socket sTR5 with AMD TRX50 chipset
  • Up to 1 TB DDR5-SDRAM memory via DIMM slots
  • Multiple storage interfaces: M.2, PCI Express 4.0, PCI Express 5.0, SATA III, with RAID levels 0, 1, 10
  • Dual LAN: 10 Gigabit Ethernet (Marvell AQtion AQC113C) and 2.5 Gigabit Ethernet (Dragon RTL8125BG)
  • Integrated Wi-Fi 6E (802.11ax) and Bluetooth for wireless connectivity
  • USB4, USB-C 3.2 Gen 2x2, USB 3.2 Gen 2, and USB 3.2 Gen 1 ports for high-speed data transfer
  • 7.1-channel HD Audio (8-channel) with onboard graphics support (CPU required)
Key Highlights
  • AMD Socket sTR5 AMD Ryzen Threadripper 1000 Series
  • PC Extended ATX AMD TRX50 Realtek ALC1220 7.1 channels
  • DDR5-SDRAM 4 DIMM Maximum internal memory: 1 TB
  • M.2, PCI Express 4.0, PCI Express 5.0, SATA III RAID support
  • BIOS type: UEFI AMI 256 Mbit Clear CMOS button
  • 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet Wi-Fi Wi-Fi 6E (802.11ax) Bluetooth 5.2
Specifications
12V power connector
Yes
Antenna included
Yes
ATX Power connector (24-pin)
Yes
Audio chip
Realtek ALC1220
Audio output channels
7.1 channels
BIOS memory size
256 Mbit
BIOS type
UEFI AMI
Bluetooth
Yes
Bluetooth version
5.2
Bundled software
Software - ASRock Motherboard Utility (A-Tuning) - ASRock Dragon 2.5G LAN Software - ASRock Polychrome SYNC* UEFI - ASRock Full HD UEFI - ASRock Auto Driver Installer - ASRock Instant Flash
Cables included
SATA
Certification
FCC, CE
Chassis intrusion connector
Yes
Clear CMOS button
Yes
Compatible processor series
AMD Ryzen Threadripper 1000 Series
Component for
PC
CPU fan connector
Yes
Depth
277 mm
ECC ?ompatibility
ECC
Ethernet interface type
2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
2
Front panel audio connector
Yes
Headphone outputs
1
LAN controller
Dragon RTL8125BG, Marvell AQtion AQC113C
M.2 standoff included
Yes
Maximum internal memory
1 TB
Memory channels
Quad-channel
Memory slots type
DIMM
Microphone in
Yes
Motherboard chipset
AMD TRX50
Motherboard chipset family
AMD
Motherboard form factor
Extended ATX
Number of chassis fan connectors
3
Number of M.2 (M) slots
2
Number of memory slots
4
Number of SATA III connectors
4
PCI Express x16 (Gen 4.x) slots
2
PCI Express x16 (Gen 5.x) slots
3
Power source type
ATX
Processor manufacturer
AMD
Processor socket
Socket sTR5
Product colour
Black
RAID levels
0, 1, 10
RAID support
Yes
S/PDIF out port
Yes
Screws included
Yes
Supported memory clock speed (max)
7600 MHz
Supported memory types
DDR5-SDRAM
Supported storage drive interfaces
M.2, PCI Express 4.0, PCI Express 5.0, SATA III
Thunderbolt headers
1
Top Wi-Fi standard
Wi-Fi 6E (802.11ax)
TPM connector
Yes
USB 2.0 connectors
2
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) connectors
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
USB 3.2 Gen 2x2 Type-C ports quantity
1
Wake-on-LAN ready
Yes
Wi-Fi
Yes
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Width
305 mm
WiFi-AP antenna jack
2
Windows operating systems supported
Windows 11

Leaflet

Open Leaflet
Price history over the last 6 months
ASRock Motherboard TRX50 Ws AMD TRX50 Ryzen 4 X DDR5 7.1ch HD Audio EATX
Current
R11,883
Lowest
R10,511
Highest
R12,225
Change 24H
-R105   -1%
Week
+R1,046   +10%
Month
+R778   +7%
