ACT RL2402 20m LC to LC Duplex Multimode OM2 Fiber Optic Patch Cable, LSZH, Aqua

ACT RL2402 20m LC to LC Duplex Multimode OM2 Fiber Optic Patch Cable, LSZH, Aqua
60 mo.
ACT RL2402 20m LC to LC Duplex Multimode OM2 Fiber Optic Patch Cable, LSZH, Aqua
R2,352
PDF
PDF
Stock 4 Code 3492283 Model RL2402 Warranty 5 Years

Shipping & Returns

Estimated delivery Thursday, December 10
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

Ask a question – the AI assistant answers instantly.

Description

Network downtime and signal loss in high-density fiber installations often stem from inferior patch cables that can't handle the demands of modern data centers. The ACT RL2402 20-meter LC to LC duplex multimode OM2 fiber optic patch cable eliminates these issues with precision-manufactured connectors and a robust LSZH jacket, ensuring reliable, high-speed connections for your critical infrastructure.

Who is it for

This cable is ideal for IT professionals, data center managers, and network engineers who need a dependable, 20-meter multimode fiber link for Gigabit Ethernet, Fast Ethernet, or other high-bandwidth applications. It's perfect for patching between switches, servers, and patch panels in enterprise environments where safety and performance are paramount.

Main features

  • 20-meter length for flexible routing in racks and across rooms
  • LC duplex connectors on both ends for secure, high-density connections
  • OM2 multimode fiber (50/125µm) supports distances up to 550m at 1Gbps and 82m at 10Gbps
  • LSZH (Low Smoke Zero Halogen) jacket in aqua for easy identification and enhanced safety
  • Low insertion loss (≤0.3dB) and high return loss (≥30dB) for optimal signal integrity
  • Cross-over polarity (A-B) for standard network configurations
  • Compliant with IEC 60793-2-10 and TIA/EIA-492AAAB standards

Specifications

  • Cable Type: Fiber Optic Patch Cable, Multimode OM2
  • Connector A: LC Duplex
  • Connector B: LC Duplex
  • Cable Length: 20 meters
  • Core/Cladding Diameter: 50/125 µm
  • Jacket Material: LSZH (Low Smoke Zero Halogen)
  • Jacket Colour: Aqua
  • Insertion Loss (Max): 0.3 dB
  • Return Loss (Min): 30 dB
  • Bandwidth: 500 MHz·km @ 850nm & 1300nm
  • Operating Temperature: -20°C to 70°C
  • Standards Compliance: IEC 60793-2-10 Type A1a.1, TIA/EIA-492AAAB

Tips

To maintain optimal performance, avoid bending the cable beyond its minimum bend radius (typically 30mm for this type) and keep connectors clean using a fiber optic cleaning kit. For installations in plenum spaces, verify local fire codes regarding LSZH cable usage.

Key Highlights
  • Up to 80% less installation time
  • No investment in splicing and testing equipment
  • Including an individual test report on attenuation IL (Insertion Loss)
  • Connectors are protected by a transparent tube during installation
  • Connectors are attached and tested in a clean room production environment
  • OM3
  • 20 m
  • 4x LC Male
  • 4x LC Male
  • Connector polish type: UPC
  • Multi-mode
  • Black

Specifications

Specifications
Attenuation
0.3 dB
Brand
ACT
Category
Fiber Optic Patch Cable
Compliance certificates
IEC 60793-2-10, TIA/EIA-492AAAB
Connector(s)
LC Duplex, LC Duplex
EAN
8716065351460
Model
RL2402
MPN
RL2402
Product colour
Aqua
Temperature range (T-T)
-20°C to 70°C

Leaflet

Open Leaflet

Manual

Open Manual

Manual

Open Manual
