Vivolink VLVWIP2000-DEC Wireless IP Camera 1080p HD

The Vivolink VLVWIP2000-DEC is a networked AV encoder/decoder system based on JPEG2000 technology that combines copper and fiber ports in a single chassis. The unit handles up to 4K@60Hz 4:4:4 video on encoder input and decoder output, supports audio embedding and extraction, and offers multiple I/O options including ARC/eARC, S/PDIF, analog audio return, USB 2.0, KVM, camera connections, 1G Ethernet, bidirectional RS-232, two-way IR and PoE power. The device runs on Linux and is designed to operate within a managed layer 3 1G network switch with IGMP snooping and 8K jumbo frame support; PoE can supply power if a PSU is not used.

Advantages

The VLVWIP2000-DEC supports HDMI 2.0b and HDCP 2.2 with up to 18 Gbps bandwidth, enabling high-quality 4K60 4:4:4 transmission. It includes standard PoE (802.3at PD) for simplified installation, built-in web GUI with drag-and-drop and image preview for easy configuration, and a MJPEG substream plus API command set for third-party control and preview. Additional features include Dante AV-A mode (license required), flexible software control via Linux, and hardware contact control with two relay channels and two I/O ports.

Suitable for

• Professional AV installations requiring high-quality 4K distribution
• Conference rooms and lecture halls with mixed copper and fiber infrastructure
• Digital signage and video wall systems (supports up to 9x9 video wall and up to 25-window multiview)
• Integrations needing RS-232, IR, CEC guest control and USB/KVM passthrough

Key specifications

• Video codec: JPEG2000
• Maximum resolution: 4K@60Hz 4:4:4
• HDMI: HDMI 2.0b; HDCP 2.2 compliant; 18 Gbps bandwidth
• Network: 1G Ethernet; requires Layer 3 managed switch with IGMP snooping and 8K jumbo frame
• Audio: ARC/eARC, S/PDIF, analog audio return; audio embedding/extraction supported
• I/O: Copper and fiber ports; USB 2.0, KVM, camera input, bidirectional RS-232, two-way IR, two relay ports, two I/O ports
• Power: PoE supported (802.3at PD); can be powered by PSU or PoE
• Control: Built-in Web GUI with drag-and-drop, MJPEG substream and API for third-party control

How to use

Install the unit in your rack or equipment location and connect source and display devices via HDMI, copper or fiber ports as required. Connect the device to a layer 3 managed 1G Ethernet switch configured with IGMP snooping and support for 8K jumbo frames. Configure IP settings and AV routing through the built-in Web GUI; use drag-and-drop operations and image preview to assign streams. Enable PoE if you prefer to power the unit over Ethernet, or use an external PSU. If needed, activate optional licenses (for example Dante AV-A) through the vendor licensing procedure.

Recommendations

For reliable multicast performance and full feature support, deploy the VLVWIP2000-DEC on a dedicated layer 3 1G managed switch with IGMP snooping enabled and 8K jumbo-frame capability; ensure HDCP and HDMI 2.0b compliance on connected displays and sources for end-to-end 4K60 4:4:4 operation.
