Victron Energy Orion-Tr 48/12-30A (360W) DC-DC Converter

The Victron Energy Orion-Tr 48/12-30A (360W) is a high-efficiency, non-isolated DC-DC step-down converter designed to convert a nominal 48V DC input to a stable 12V DC output. With a continuous output current of 30A and power of 360W, it is ideal for applications such as telecom, industrial, and automotive systems where reliable voltage conversion is required. The converter features remote on/off capability, screw terminal connections, and comprehensive protection against short circuit, over temperature, and input over/under voltage.

Advantages

High efficiency of over 92% minimizes power loss and heat generation. Compact and robust design with IP43 protection rating when installed vertically. Wide input voltage range (32-70V) ensures compatibility with various battery systems. Low standby current (<20mA) and excellent voltage regulation (<±0.2%) provide stable performance.

Suitable for

• Telecommunication equipment
• Industrial control systems
• Automotive and marine electronics
• Renewable energy systems (e.g., solar battery banks)
• LED lighting and audio systems

Key specifications

• Input voltage nominal: 48V DC (range 32-70V)
• Output voltage nominal: 12V DC (adjustable 10-15V)
• Output current continuous: 30A
• Output power continuous: 360W
• Efficiency: >92%
• Topology: Step-down (Buck) DC-DC converter
• Remote on/off: Yes
• Operating temperature: -20 to +55°C (derating above 40°C)
• Protection: Short circuit, over temperature, input over/under voltage
• Enclosure protection: IP43 (vertical installation)
• Connection: Screw terminals
• Standby current: <20mA
• Voltage regulation: <±0.2%
• Ripple and noise: <100mV RMS

Recommendations

For optimal performance, install the converter vertically with screw terminals facing downwards to maintain IP43 rating. Ensure adequate ventilation and avoid exceeding 40°C ambient temperature without derating. Use appropriate wire gauge for 30A output.
