VALUE LC to ST Multimode Duplex Fiber Patch Cable, OM2 50/125 µm, 1 m, Orange

In modern data centers and enterprise networks, reliable high-speed optical links are non-negotiable. The VALUE LC to ST Multimode Duplex Fiber Patch Cable delivers a robust 1-meter connection between LC and ST interfaces, using OM2 50/125 µm multimode fiber. It is built for short-reach interconnects where consistent signal integrity and low insertion loss matter most.

Who is it for

Network administrators, data center technicians, and system integrators who need a dependable fiber patch cord for patching between LC and ST equipment. Ideal for legacy ST-based infrastructure that must interface with modern LC ports on switches, media converters, or patch panels.

Main features

• Duplex multimode fiber with 50/125 µm core/cladding for OM2 performance.
• LC male connector on one end, ST male connector on the other.
• UPC polish on both connectors for low back reflection.
• Orange PVC jacket for easy identification and durability.
• Insertion loss less than 0.3 dB, return loss greater than 30 dB.
• Compliant with TIA/EIA-568-C.3, ISO/IEC 11801, and RoHS.

Specifications

• Cable type: Fiber optic patch cable, duplex
• Fiber class: OM2 multimode
• Core/cladding diameter: 50/125 µm
• Connector A: LC male
• Connector B: ST male
• Connector polish: UPC
• Cable length: 1.0 m
• Jacket material: PVC
• Jacket color: Orange
• Cable diameter: 3.0 mm
• Insertion loss: < 0.3 dB
• Return loss: > 30 dB
• Operating temperature: -20°C to 70°C
• Standards: TIA/EIA-568-C.3, ISO/IEC 11801, RoHS

Tips

For best performance, keep bend radius above 30 mm and avoid pulling on connectors. Use dust caps when ports are not in use. Pair with OM2-compatible transceivers for 1 Gbps and 10 Gbps short-reach links.
