UGREEN CM692 HDMI KVM Switch 2 In 1 Out

The UGREEN CM692 HDMI KVM Switch 2 In 1 Out allows you to control two computers with a single monitor, keyboard, and mouse. It supports 4K@60Hz resolution and features USB 2.0 ports for peripheral sharing. The switch is plug-and-play, compatible with Windows, macOS, and Linux, and offers switching via push button or keyboard hotkeys.

Advantages

Efficiently manage two computers from one workstation, saving desk space and reducing cable clutter. Enjoy high-quality 4K video at 60Hz with HDCP 2.2 support. The aluminum alloy housing ensures durability and heat dissipation.

Suitable for

• Home offices with multiple computers
• IT professionals managing multiple systems
• Gamers switching between gaming and work PCs

Key specifications

• KVM Type: HDMI KVM Switch
• Number of Computers Supported: 2
• Number of Monitors Supported: 1
• Video Input Ports: 2x HDMI
• Video Output Ports: 1x HDMI
• Peripheral USB Ports: 2x USB-A 2.0
• Host USB Ports: 2x USB-B 2.0
• Maximum Video Resolution: 4K (3840x2160) @ 60Hz
• Backward Resolution Compatibility: 2K@120Hz, 1080P@144Hz/120Hz/60Hz
• USB Data Transfer Rate: Up to 480Mbps
• HDCP Support: HDCP 2.2 / 1.4
• Audio Support: Yes (via HDMI)
• Switching Methods: Push Button, Keyboard Hotkeys
• Power Supply: USB Powered (Optional Micro USB 5V/1A for stable power)
• Shell Material: Aluminum Alloy
• Operating System Compatibility: Windows, macOS, Linux
• Plug & Play: Yes
• EDID Emulation: Yes

Recommendations

For optimal performance, use high-quality HDMI and USB cables. If experiencing instability, connect the optional Micro USB power cable.
