Portable audio recorder Tascam FR2-AV — 2-track, 2 XLR combo inputs, USB-C interface, 48–192 kHz, 24/32-bit, microSD up to 512 GB

Tascam FR2-AV is a portable 2-track audio recorder and USB audio interface designed for field recording and simple studio tasks. It features two XLR combo inputs with phantom power, a 3.5 mm input, a 3.5 mm headphone output and USB-C connectivity. The unit supports WAV recording at 48, 96 and 192 kHz with 24- or 32-bit resolution and accepts microSD cards up to 512 GB. The recorder is compact and lightweight, runs on three AA batteries or USB power (USB PD) and includes a 2" colour LCD for monitoring and menu navigation.

Advantages

The device provides dual XLR combo inputs for professional microphone connections and phantom power for condenser microphones. High sample rates and 24/32-bit resolution allow for detailed captures, while USB-C support and compatibility with major desktop and mobile operating systems enable use as an audio interface. Compact dimensions and low weight make it convenient for on-location work, and support for large-capacity microSD cards offers extended recording time.

Suitable for

• Field interviews and journalism
• Location sound for video and film
• Live music rehearsals and simple stereo recordings
• Podcasting and voiceover recording

Key specifications

• Channels: 2-track
• Inputs: 2 XLR combo inputs, 1 × 3.5 mm jack input
• Headphone output: 1 × 3.5 mm
• Audio formats: WAV
• Sample rates: 48 kHz / 96 kHz / 192 kHz
• Bit depth: 24-bit / 32-bit
• Display: 2" (5 cm) colour LCD
• Storage: microSD / microSDHC support, up to 512 GB
• Power: 3 × AA batteries or USB Power Delivery (USB-C)
• Ports: USB Type-C interface
• Operating temperature range: 0 °C to 40 °C
• Dimensions (W × D × H): 99 × 40.3 × 80.4 mm
• Weight: 195 g

How to use

Install a compatible microSD card and optional AA batteries or connect a USB-C power source. Connect microphones to the XLR combo inputs or a line-level source to the 3.5 mm input, enable phantom power if using condenser microphones, set the desired sample rate and bit depth, and monitor levels on the 2" colour LCD. Use the headphone output for real-time monitoring and connect the recorder to a computer or mobile device via USB-C to use it as an audio interface or transfer files.

Recommendations

Protect the recorder from extreme temperatures and avoid prolonged exposure to heat or cold. Use high-quality microSD cards rated for sustained audio recording and fresh AA batteries or a stable USB PD power source for reliable operation.
