Power adapter/inverter MEAN WELL RDDW10H-15, 10 W, Input 43–160 V, Output 15 V

MEAN WELL RDDW10H-15 is a compact DC-DC railway dual output converter with wide input range and fixed ±15 VDC outputs. It accepts 43–160 VDC input and provides ±15 VDC at ±0.333 A with 1.5 kVDC input-to-output isolation. The module is supplied in a DIP through‑hole package, includes remote ON/OFF control and is intended for embedded systems, industrial electronics and small automation tasks requiring a stable wide‑range power solution.

Advantages

The RDDW10H-15 offers a wide 43–160 VDC input range, dual ±15 V outputs with 1.5 kVDC isolation between input and output, and compact DIP through‑hole packaging for easy board mounting. At 10 W output power and a lightweight 16 g construction it is suited to space‑ and weight‑sensitive applications while meeting RoHS requirements. Remote ON/OFF function allows controlled power sequencing in system designs.

Suitable for

• Embedded systems and control boards
• Industrial electronics and railway signaling equipment
• Small automation modules and distributed power supplies

Key specifications

• Manufacturer: MEAN WELL
• Model: RDDW10H-15 (MPN)
• Input voltage: 43–160 VDC
• Output: ±15 VDC at ±0.333 A (dual output)
• Output power: 10 W
• Isolation: 1.5 kVDC input-to-output
• Package: DIP through‑hole
• Remote ON/OFF: yes
• Weight: 16 g
• Compliance: RoHS
• EAN: 4021087048620

How to use

Install the DIP through‑hole module on the target PCB following the manufacturer’s recommended footprint and soldering guidelines. Connect the input to a DC source within 43–160 VDC, observe polarity, and wire the dual ±15 V outputs to the load respecting current limits (±0.333 A). Use the remote ON/OFF pin to control power sequencing; consult the MEAN WELL datasheet for logic levels and timing. Ensure adequate creepage, clearance and mounting for the stated 1.5 kVDC isolation.

Recommendations

Provide appropriate input filtering and decoupling at the module input and output, maintain specified ambient temperature ranges and allow ventilation or heatsinking as recommended by MEAN WELL. Verify that connected loads do not exceed the ±0.333 A per rail rating and follow railway or industrial installation standards where applicable.
