Planet MTB-Series MTB-TSR SFP+ Transceiver Module 10GBASE-T RJ45 30m

The Planet MTB-TSR is a high-performance SFP+ transceiver module designed for 10 Gigabit Ethernet over copper cabling. Part of the reliable MTB-Series, this module enables seamless integration of 10GBASE-T connectivity into network switches, routers, and other devices with SFP+ slots. It supports distances up to 30 meters over Cat.6a or Cat.7 cable, making it ideal for high-speed data center and enterprise network uplinks.

Advantages

Cost-effective 10G connectivity using standard copper cabling; hot-pluggable design for easy installation and maintenance; supports Digital Diagnostic Monitoring (DDM) for real-time performance tracking; low power consumption under 3.5W reduces energy costs; MSA compliant for broad compatibility with Planet and third-party equipment.

Suitable for

• 10 Gigabit Ethernet uplinks in data centers
• Enterprise network backbone connections
• High-bandwidth server and storage area networks
• Copper-based 10G deployments where fiber is not required

Key specifications

• Module Type: SFP+
• Data Rate: 10 Gbps
• Interface: 10GBASE-T
• Connector: RJ45
• Cable: Cat.6a / Cat.7 Copper
• Max Distance: 30 meters
• Hot-Pluggable: Yes
• DDM/DOM Support: Yes
• Power Consumption: <3.5W
• Operating Temperature: 0°C to 70°C
• Standards: IEEE 802.3ae, SFF-8431, SFF-8432
• Voltage: 3.3V
• RoHS Compliant: Yes

Recommendations

For optimal performance, use high-quality Cat.6a or Cat.7 shielded copper cabling. Ensure your switch or device supports SFP+ 10GBASE-T modules. This module is not compatible with SFP slots or 1G networks.
