PLANET MTB-LA10 10G SFP+ Fiber Transceiver - 10GBASE-LR (1310nm, LC, SMF, 10km)

Scaling your network to 10 Gigabit Ethernet doesn’t have to mean replacing core switches and routers. The PLANET MTB-LA10 SFP+ transceiver gives you a straightforward, cost-effective way to add 10G connectivity over single-mode fiber, delivering reliable long-haul links without complex rewiring. As a hot-swappable module, it slots directly into any SFP+ port, allowing you to upgrade or service connections while the network stays live.

Who is it for

This module is ideal for network engineers, IT managers, and system integrators who need to expand enterprise backbones, data-center interconnects, or campus networks with 10GBASE-LR links. It’s especially useful when operating distances extend beyond 300 m, where multi-mode options fall short.

Main features

• 10GBASE-LR standard for long-range single-mode fiber transmission
• LC duplex connector and 1310nm DFB laser for stable optical performance
• Supports up to 10 km link distance over OS2 single-mode fiber
• Digital Diagnostic Monitoring (DDM) for real-time monitoring of voltage, temperature, TX/RX power
• Hot-swap capability minimizes downtime during installation and replacement
• Low power consumption under 1W for efficient network operation

Specifications

• Transceiver type: SFP+
• Interface standard: IEEE 802.3ae 10GBASE-LR
• Maximum data transfer rate: 10000 Mbit/s
• Wavelength: 1310 nm
• Fiber optic connector: LC duplex
• Maximum transfer distance: 10 km (6.2 miles)
• Single-mode fiber (SMF) supported: Yes
• Hot-Plug support: Yes
• Operating temperature: 0 to 70°C (32 to 158°F)
• Storage temperature: -40 to 85°C (-40 to 185°F)
• Operating relative humidity: 0% to 85% non-condensing
• Power supply: 3.3V
• Typical power consumption: < 1W
• Standards compliance: IEEE 802.3ae, SFP+ MSA, RoHS

Tips

Before deploying, confirm your switch or media converter supports SFP+ modules and check the module’s DDM information after insertion to ensure proper optical signal levels. Pair the MTB-LA10 with a corresponding 10GBASE-LR module at the far end and use single-mode fiber with an LC connection for best results.
