Motherboard GIGABYTE B650 EAGLE AX ATX, AMD B650 chipset, Socket AM5, DDR5, 4x DIMM, 256GB, Wi‑Fi 6E, Bluetooth 5.3

Motherboard GIGABYTE B650 EAGLE AX ATX, AMD B650 chipset, Socket AM5, DDR5, 4x DIMM, 256GB, Wi‑Fi 6E, Bluetooth 5.3
Motherboard GIGABYTE B650 EAGLE AX ATX, AMD B650 chipset, Socket AM5, DDR5, 4x DIMM, 256GB, Wi‑Fi 6E, Bluetooth 5.3
Motherboard GIGABYTE B650 EAGLE AX ATX, AMD B650 chipset, Socket AM5, DDR5, 4x DIMM, 256GB, Wi‑Fi 6E, Bluetooth 5.3
Motherboard GIGABYTE B650 EAGLE AX ATX, AMD B650 chipset, Socket AM5, DDR5, 4x DIMM, 256GB, Wi‑Fi 6E, Bluetooth 5.3
Motherboard GIGABYTE B650 EAGLE AX ATX, AMD B650 chipset, Socket AM5, DDR5, 4x DIMM, 256GB, Wi‑Fi 6E, Bluetooth 5.3
Motherboard GIGABYTE B650 EAGLE AX ATX, AMD B650 chipset, Socket AM5, DDR5, 4x DIMM, 256GB, Wi‑Fi 6E, Bluetooth 5.3
36 mo.
Motherboard GIGABYTE B650 EAGLE AX ATX, AMD B650 chipset, Socket AM5, DDR5, 4x DIMM, 256GB, Wi‑Fi 6E, Bluetooth 5.3
Motherboard GIGABYTE B650 EAGLE AX ATX, AMD B650 chipset, Socket AM5, DDR5, 4x DIMM, 256GB, Wi‑Fi 6E, Bluetooth 5.3
Motherboard GIGABYTE B650 EAGLE AX ATX, AMD B650 chipset, Socket AM5, DDR5, 4x DIMM, 256GB, Wi‑Fi 6E, Bluetooth 5.3
Motherboard GIGABYTE B650 EAGLE AX ATX, AMD B650 chipset, Socket AM5, DDR5, 4x DIMM, 256GB, Wi‑Fi 6E, Bluetooth 5.3
Motherboard GIGABYTE B650 EAGLE AX ATX, AMD B650 chipset, Socket AM5, DDR5, 4x DIMM, 256GB, Wi‑Fi 6E, Bluetooth 5.3
Motherboard GIGABYTE B650 EAGLE AX ATX, AMD B650 chipset, Socket AM5, DDR5, 4x DIMM, 256GB, Wi‑Fi 6E, Bluetooth 5.3
R2,935
The GIGABYTE B650 EAGLE AX is an ATX motherboard based on the AMD B650 chipset and designed for Socket AM5 processors. It supports AMD Ryzen 9000 Series CPUs and up to 256 GB of DDR5 memory (4 slots, up to 7600 MHz OC). The board includes a 12+2+2-phase VRM design for stable power delivery, one PCIe... Read More
Stock 153 Code 28944 Brand GIGABYTE Model B650 EAGLE AX Warranty 3 Years

Shipping & Returns

Estimated delivery Wednesday, September 30
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

The GIGABYTE B650 EAGLE AX is an ATX motherboard based on the AMD B650 chipset and designed for Socket AM5 processors. It supports AMD Ryzen 9000 Series CPUs and up to 256 GB of DDR5 memory (4 slots, up to 7600 MHz OC). The board includes a 12+2+2-phase VRM design for stable power delivery, one PCIe 5.0 x16 slot, three PCIe x16 (Gen3.x) physical slots, two PCIe 4.0 M.2 slots, GbE LAN, Wi‑Fi 6E and multiple USB 3.2 Gen 2 ports. RAID 0, 1 and 10 are supported for compatible storage configurations.

Advantages

The GIGABYTE B650 EAGLE AX offers a robust power design and high memory frequency support to meet demanding workloads. Its PCIe 5.0 x16 slot and dual PCIe 4.0 M.2 slots provide flexibility for high-speed graphics and NVMe storage. Integrated GbE LAN and Wi‑Fi 6E ensure modern network connectivity, while support for USB 3.2 Gen 2 enables fast peripheral data transfer. The ATX form factor and ample expansion options make this motherboard suitable for versatile PC builds.

Suitable for

  • High-performance desktop builds with AMD Ryzen 9000 Series CPUs
  • Gaming systems requiring PCIe 5.0 graphics support
  • Content creation and workstation use with fast NVMe storage
  • Upgradable systems needing multiple expansion slots and high memory capacity

Key specifications

  • Form factor: ATX
  • Chipset: AMD B650
  • Socket: AM5
  • VRM design: 12+2+2 Phases
  • Memory: 4 x DDR5 slots, up to 256 GB, up to 7600 MHz (OC)
  • PCIe slots: 1 x PCIe 5.0 x16, 3 x PCIe x16 (Gen3.x)
  • Storage: 2 x PCIe 4.0 M.2 slots, RAID 0/1/10 support
  • Networking: GbE LAN, Wi‑Fi 6E
  • USB: USB 3.2 Gen 2 ports

How to use

Install the GIGABYTE B650 EAGLE AX into a compatible ATX chassis and fit an AMD Socket AM5 processor following the motherboard manual. Populate DDR5 memory modules in matched pairs to enable optimal dual-channel performance, and install graphics and storage devices into the appropriate PCIe and M.2 slots. Connect power supply cables, front-panel connectors and cooling solutions, then configure BIOS settings for memory overclocking or RAID arrays as required.

Recommendations

For stable operation with high-frequency DDR5 memory and CPU overclocking, use a high-quality power supply and adequate case airflow. Update the motherboard BIOS to the latest version before first boot to ensure full CPU and memory compatibility.
Key Highlights
  • AMD Socket AM5:Supports AMD Ryzen 7000/ Ryzen 8000/ Ryzen 9000 Series Processors
  • Unparalleled Performance:12+2+2 Phases Digital VRM Solution
  • Dual Channel DDR5:4*SMD DIMMs with AMD EXPO & Intel XMP Memory Module Support
  • SuperSpeed Storage:1*PCIe 5.0 + 2*PCIe 4.0 M.2 Connectors
  • Advanced Thermal Design & M.2 Thermal Guard:To Ensure VRM Power Stability & 25110 M.2 SSD Performance
  • EZ-Latch:PCIe x16 Slot with Quick Release Design
  • Fast Networks:Wi-Fi 6E 802.11ax & GbE LAN
  • Extended Connectivity:DP, HDMI, Rear USB 10Gb/s
  • Smart Fan 6:Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
  • Q-Flash Plus:Update BIOS Without Installing the CPU, Memory and Graphics Card
  • AMD Socket AM5 AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
  • PC ATX AMD B650 Realtek ALC897 7.1 channels
  • DDR5-SDRAM 4 DIMM Maximum internal memory: 256 GB
  • HDD & SSD M.2, SATA III RAID support Number of storage drives supported: 7
  • BIOS type: UEFI AMI 256 Mbit ACPI version: 5.0 Clear CMOS jumper
  • Gigabit Ethernet Wi-Fi Wi-Fi 6E (802.11ax) Bluetooth 5.3
Specifications
12V power connector
Yes
1st M.2 highest PCI Express generation
5.0
1st M.2 largest key size
25110
2nd M.2 highest PCI Express generation
4.0
2nd M.2 largest key size
22110
3rd M.2 highest PCI Express generation
4.0
3rd M.2 largest key size
22110
ACPI version
5.0
Antenna included
Yes
ATX Power connector (24-pin)
Yes
Audio chip
Realtek ALC897
Audio output channels
7.1 channels
Batteries included
Yes
Battery technology
Lithium-Manganese Dioxide (LiMnO2)
Battery type
CR2032
Battery weight
3 g
BIOS memory size
256 Mbit
BIOS type
UEFI AMI
Bluetooth
Yes
Bluetooth version
5.3
Bundled software
Norton Internet Security (OEM version) LAN bandwidth management software
Clear CMOS jumper
Yes
Compatible processor series
AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Component for
PC
Country of origin
China
CPU fan connector
Yes
Depth
244 mm
Desktop Management Interface (DMI) version
2.7
DirectX version
12.0
Discrete graphics support
Yes
DisplayPort version
1.4
DisplayPorts quantity
1
DVI-D ports quantity
0
ECC сompatibility
Non-ECC
EPS power connector (8-pin)
Yes
Ethernet interface type
Gigabit Ethernet
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Front panel audio connector
Yes
Front panel connector
Yes
HDCP
Yes
HDMI ports quantity
1
HDMI version
2.1
Headphone outputs
1
Height
35 mm
LAN controller
Realtek RTL8111H
Line-in
Yes
Lithium weight per battery
0.07 g
Maximum internal memory
256 GB
Maximum internal memory per slot
64 GB
Maximum resolution
4096 x 2160 pixels
Memory channels
Dual-channel
Memory slots type
DIMM
Microphone in
Yes
Motherboard chipset
AMD B650
Motherboard chipset family
AMD
Motherboard form factor
ATX
Number of battery cells
1
Number of chassis fan connectors
3
Number of CPU fan connectors
2
Number of HDDs supported
4
Number of M.2 (M) slots
3
Number of memory slots
4
Number of RGB LED pin headers
4
Number of SATA III connectors
4
Number of storage drives supported
7
Number of water pump connectors
2
Package depth
270 mm
Package height
80 mm
Package weight
1.94 kg
Package width
335 mm
Parallel processing technology support
Not supported
PC health monitoring
Fan, Temperature, Voltage, Water cooling
PCI Express x16 (Gen 3.x) slots
3
PCI Express x16 (Gen 4.x) slots
1
Power source type
ATX
Processor manufacturer
AMD
Processor socket
Socket AM5
Product colour
Brown
Products per shipping (inner) case
1 pc(s)
PS/2 ports quantity
1
RAID levels
0, 1, 10
RAID support
Yes
RGB LED pin header
Yes
Screws included
Yes
Serial port headers
1
Supported memory clock speed (max)
7600 MHz
Supported memory clock speeds
7600,7200,7000,6800,6600,6400,6200,6000,5600,5200,4800,4400 MHz
Supported memory types
DDR5-SDRAM
Supported processor sockets
Socket AM5
Supported storage drive interfaces
M.2, SATA III
Supported storage drive types
HDD & SSD
System Management BIOS (SMBIOS) version
2.7
Top Wi-Fi standard
Wi-Fi 6E (802.11ax)
TPM connector
Yes
Unbuffered memory
Yes
USB 2.0 connectors
3
USB 2.0 ports quantity
6
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) connectors
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
VGA (D-Sub) ports quantity
0
Warranty period
3 year(s)
Wi-Fi
Yes
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Width
305 mm
WiFi-AP antenna jack
2
Windows operating systems supported
Windows 10 x64, Windows 11 x64
WLAN controller model
Realtek RTL8852CE

Manual

Open Manual

Leaflet

Open Leaflet
