MSI B760 GAMING PLUS WIFI DDR4 motherboard Intel B760 LGA 1700 ATX

MSI B760 GAMING PLUS WIFI DDR4 motherboard Intel B760 LGA 1700 ATX
MSI B760 GAMING PLUS WIFI DDR4 motherboard Intel B760 LGA 1700 ATX
MSI B760 GAMING PLUS WIFI DDR4 motherboard Intel B760 LGA 1700 ATX
MSI B760 GAMING PLUS WIFI DDR4 motherboard Intel B760 LGA 1700 ATX
36 mo.
MSI B760 GAMING PLUS WIFI DDR4 motherboard Intel B760 LGA 1700 ATX
MSI B760 GAMING PLUS WIFI DDR4 motherboard Intel B760 LGA 1700 ATX
MSI B760 GAMING PLUS WIFI DDR4 motherboard Intel B760 LGA 1700 ATX
MSI B760 GAMING PLUS WIFI DDR4 motherboard Intel B760 LGA 1700 ATX
R3,490
B760 GAMING PLUS WIFI DDR4The B760 GAMING PLUS WIFI DDR4 is crafted to offer extensive connectivity, versatile tools, and a convenient Wi-Fi solution for gamers seeking a comprehensive experience. Featuring 2.5G LAN, Wi-Fi 6E, DDR4 support, PCIe 4.0 capabilities, and dual M.2 connectors, it is optim... Read More
Stock 2 Code 105100 Brand MSI Model B760 GAMING PLUS WIFI DDR4 Warranty 3 Years

Shipping & Returns

Estimated delivery Thursday, October 1
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival
B760 GAMING PLUS WIFI DDR4
The B760 GAMING PLUS WIFI DDR4 is crafted to offer extensive connectivity, versatile tools, and a convenient Wi-Fi solution for gamers seeking a comprehensive experience. Featuring 2.5G LAN, Wi-Fi 6E, DDR4 support, PCIe 4.0 capabilities, and dual M.2 connectors, it is optimized for Intel® Core 14th /13th /12th Gen processors.

Extended Heatsink
Extended Heatsink enlarges the surface of heat dissipation, ensuring even high-end processors to run in full speed.

Heavy Plated VRM Heatsink
The VRM heatsink covers the upper MOS and helps dissipate the heat.

M.2 Shield Frozr
Keeps M.2 SSDs safe while preventing throttling, making them run faster.

7W/mK Thermal Pad & Additional Choke Pad
High quality 7W/mK MOSFET thermal pads and extra choke thermal pads ensure all cores running in high performcance.

DIY 2.0 – INTEGRATING WITH THE SYSTEM ENVIRONMENT
Connect and synchronize with MSI coolers and cases with strategically positioned pin-header locations including a dedicated pump-fan header.

OPTIMIZED FOR WATER COOLING
Designed to support the most popular All-In-One & customized water cooling solutions on the market. A dedicated water pump PIN header supports up to 3 amp, giving you full control of the water pump speed. A clearly marked ‘keep-out-zone’ allows for easy and safe installation and a perfect fit.

LIGHTNING GEN 4 PCI-E
Doubling over the previous generation, the bandwidth of a x16 interface can reach 64GB/s.

REINFORCED,
HEAVY SOLDERED CONNECTIONS
Secure to the motherboard with extra solder points and support the weight of heavy graphics cards.
FAST AND FUTURE-READY STORAGE
B760 GAMING PLUS WIFI DDR4 motherboards support all the latest storage standards, which allows users to connect any ultra-fast storage device. Start games faster, load levels faster and have a real advantage over your enemies.

MSI B760 GAMING PLUS WIFI DDR4. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processor series: Intel® Celeron®, Intel® Pentium® Gold. Supported memory types: DDR4-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA, RAID levels: 0, 1, 5, 10. Ethernet interface type: 2.5 Gigabit Ethernet, LAN controller: Dragon RTL8125BG, Top Wi-Fi standard: Wi-Fi 6 (802.11ax). Component for: PC, Motherboard form factor: ATX, Motherboard chipset family: Intel

Key Highlights
  • Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors for LGA 1700 socket
  • Supports DDR4 Memory, up to 5333+(OC) MHz
  • Enhanced Power Design: 12+1 Duet Rail Power System with P-PAK, 8-pin + 4-pin CPU power connectors, Core Boost, Memory Boost
  • Premium Thermal Solution: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads are built for high performance system and non-stop gaming experience
  • Lightning Fast Game experience: PCIe 4.0 slot, Lightning Gen 4 x4 M.2 with M.2 Shield Frozr, USB 3.2 Gen 2 10G
  • 2.5G LAN with Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
  • High Quality PCB: 6-layer PCB made by 2oz thickened copper
  • Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience
  • Intel LGA 1700 Intel® Celeron®, Intel® Pentium® Gold
  • PC ATX Intel B760 Realtek ALC897 7.1 channels
  • DDR4-SDRAM 4 DIMM Maximum internal memory: 128 GB
  • M.2, SATA RAID support Number of storage drives supported: 6
  • BIOS type: UEFI AMI 256 Mbit ACPI version: 6.4
  • 2.5 Gigabit Ethernet Wi-Fi Wi-Fi 6 (802.11ax) Bluetooth 5.3
Specifications
ACPI version
6.4
Audio chip
Realtek ALC897
Audio output channels
7.1 channels
BIOS memory size
256 Mbit
BIOS type
UEFI AMI
Bluetooth
Yes
Bluetooth version
5.3
Compatible processor series
Intel® Celeron®, Intel® Pentium® Gold
Component for
PC
Depth
304.8 mm
DisplayPort version
1.4
DisplayPorts quantity
1
DVI-D ports quantity
0
ECC сompatibility
Non-ECC
Ethernet interface type
2.5 Gigabit Ethernet
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
HDMI ports quantity
1
HDMI version
2.1
LAN controller
Dragon RTL8125BG
Maximum internal memory
128 GB
Maximum internal memory supported by processor
128 GB
Memory channels
Dual-channel
Memory slots type
DIMM
Motherboard chipset
Intel B760
Motherboard chipset family
Intel
Motherboard form factor
ATX
Number of HDDs supported
4
Number of M.2 (M) slots
2
Number of memory slots
4
Number of SATA III connectors
4
Number of storage drives supported
6
PCI Express x1 (Gen 3.x) slots
3
PCI Express x1 slots
3
PCI Express x16 (Gen 4.x) slots
2
PCI Express x16 slots
2
Processor manufacturer
Intel
Processor socket
LGA 1700
RAID levels
0, 1, 5, 10
RAID support
Yes
RGB LED pin header
Yes
S/PDIF out connector
Yes
S/PDIF out port
Yes
Supported memory clock speeds
2133,2400,2666,2933,3200,3333,3400,3466,3600,3733,3800,4000,4200,4266,4400,4600,4800,5000,5066,5200,5333 MHz
Supported memory types
DDR4-SDRAM
Supported processor sockets
LGA 1700
Supported storage drive interfaces
M.2, SATA
Top Wi-Fi standard
Wi-Fi 6 (802.11ax)
Total number of SATA connectors
4
TPM connector
Yes
USB 2.0 connectors
4
USB 2.0 ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) connectors
3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
VGA (D-Sub) ports quantity
0
Wi-Fi
Yes
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Width
243.8 mm
Windows operating systems supported
Windows 10 x64, Windows 11 x64

Leaflet

Open Leaflet

Manual

Open Manual
