Giada D612 Fanless Mini PC Intel Core i5-1235U 10C/12T Iris Xe 2x DDR4 2x 2.5GbE

The Giada D612 is a fanless mini PC engineered around the Intel Core i5-1235U processor, delivering 10 cores and 12 threads with a turbo frequency up to 4.4 GHz. Its aluminum alloy chassis dissipates heat silently, making it ideal for always-on digital signage, industrial control, and edge computing where dust and noise are unacceptable.

Advantages

The hybrid architecture of the i5-1235U combines two performance cores with eight efficiency cores, balancing responsiveness and energy savings. Intel Iris Xe graphics drive up to three 4K displays via HDMI 2.0, DisplayPort 1.4, and USB-C with DP Alt Mode. Dual Intel I225-V 2.5 Gigabit Ethernet ports enable high-speed networking and failover, while two RS232 serial ports support legacy industrial equipment. The fanless design eliminates moving parts, reducing maintenance and extending lifespan in harsh environments.

Suitable for

• Digital signage and kiosk systems requiring 24/7 silent operation
• Industrial automation and machine control with serial connectivity
• Edge computing and IoT gateways needing dual 2.5GbE networking
• Thin client and office productivity with multi-monitor support
• Home lab and firewall applications with low power consumption

Key specifications

• Processor: Intel Core i5-1235U, 10 cores (2P+8E), 12 threads, up to 4.4 GHz
• Graphics: Intel Iris Xe Graphics (80 EUs)
• Memory: 2 x DDR4 SO-DIMM slots, up to 64 GB at 3200 MHz
• Storage: 1 x M.2 2280 PCIe Gen4 x4 + 1 x 2.5" SATA
• Networking: 2 x Intel I225-V 2.5 Gigabit Ethernet
• Video outputs: 1 x HDMI 2.0, 1 x DisplayPort 1.4, 1 x USB-C (DP Alt Mode)
• USB: 2 x USB 3.2 Gen2, 2 x USB 2.0, 1 x USB-C
• Serial: 2 x RS232
• Expansion: M.2 E-key for Wi-Fi/Bluetooth (module optional)
• Power: DC 12V/5A (60W)
• OS support: Windows 10/11, Linux
• Chassis: Fanless aluminum alloy

Recommendations

For deployments that demand silent, reliable computing with legacy serial and modern high-speed networking, the Giada D612 offers a robust platform. Pair it with industrial SSDs and validated DDR4 modules for maximum stability in critical applications.
