Eurolite HPE Proactive Care 24x7 Service Post Warranty

The Eurolite HPE Proactive Care 24x7 Service Post Warranty is a professional DMX splitter/distributor designed for reliable signal distribution in demanding lighting applications. This 1U 19-inch rack-mountable unit features electrical isolation between input and outputs, ensuring clean signal transmission and protection of connected equipment.

Advantages

With 4 optically isolated outputs, the Eurolite DMX splitter regenerates and amplifies the DMX signal, preventing signal degradation over long cable runs. The combination of XLR 3-pin and XLR 5-pin connectors offers flexibility for various DMX setups. Its compact 1U design saves rack space while providing robust performance.

Suitable for

• Professional stage lighting installations
• Event technology and touring systems
• Club and venue lighting infrastructure
• Broadcast and studio environments

Key specifications

• DMX Standard: DMX512
• Input Connectors: 1x XLR 3-pin, 1x XLR 5-pin
• Output Connectors: 4x XLR 3-pin, 4x XLR 5-pin
• Number of Outputs: 4
• Isolation: Electrical isolation between input and outputs, and between individual outputs
• Mounting: 19-inch Rack Mountable, 1U
• Power Supply: AC 230 V, 50 Hz
• Power Consumption: Approx. 5 W
• Indicators: Power LED, DMX Input Signal LED, 4x DMX Output Signal LEDs
• Housing Material: Metal
• Operating Temperature: 0 - 40 °C
• Humidity: 0 - 90 % (non-condensing)
• Signal Amplification: Yes (re-generates DMX signal)
• Input/Output Buffering: Yes
• Included Accessories: Power cable

Recommendations

For optimal performance, use high-quality DMX cables and ensure proper termination. The Eurolite DMX splitter is ideal for expanding DMX networks and maintaining signal integrity in complex lighting systems.
