EFB Elektronik Fiber Optic Patch Cable LC/APC Single-mode (M) 1 m Yellow

The EFB Elektronik fiber optic patch cable is a high-performance single-mode duplex cable designed for reliable data transmission in indoor networks. With LC/APC connectors on both ends and a length of 1 meter, it ensures low insertion loss and high return loss, making it ideal for FTTH, CATV, and telecommunication applications.

Advantages

This cable features G.657.A2 (OS2) fiber with 9/125 µm core/cladding, providing excellent bend resistance and signal integrity. The LSZH jacket ensures safety in enclosed spaces, while the yellow color indicates single-mode fiber for easy identification.

Suitable for

• Fiber-to-the-home (FTTH) installations
• Data center and server room connections
• Telecommunication and CATV networks
• Indoor backbone cabling

Key specifications

• Cable type: Fiber Optic Patch Cable
• Fiber mode: Single-mode (SM) OS2
• Connectors: LC/APC to LC/APC
• Length: 1 m
• Fiber count: 2 (duplex)
• Jacket material: LSZH (Low Smoke Zero Halogen)
• Jacket color: Yellow
• Insertion loss: < 0.3 dB typical
• Return loss: > 60 dB typical
• Polish: APC (Angled Physical Contact)
• Operating temperature: -20°C to 70°C
• Compliance: RoHS, REACH

Recommendations

For optimal performance, ensure connectors are clean before installation. This cable is compatible with all standard LC/APC interfaces and is suitable for 1G, 10G, and 40G applications.
