EFB-ELEKTRONIK D-Sub Solder Connector 15-Pin Male DE-15 EDS 15 LL /Z

The EFB-ELEKTRONIK D-Sub solder connector, model 28656.1, is a high-quality 15-pin male plug designed for reliable signal transmission in data and industrial applications. Part of the EDS series, this connector features a solder cup termination for secure wire attachment and a robust cable mount design. The DE-15 shell size ensures compatibility with standard D-Sub interfaces.

Advantages

Gold-plated contacts provide excellent conductivity and corrosion resistance, ensuring long-term performance. The nickel-plated steel shell offers durability and effective shielding against electromagnetic interference. With a current rating of 5 A per contact and a voltage rating of 250 V, it is suitable for a wide range of signal and low-power applications.

Suitable for

• Data transmission and signal connections in computer, networking, and industrial equipment
• Custom cable assemblies requiring solder termination
• Replacement or repair of D-Sub connectors in various electronic devices

Key specifications

• Connector Type: D-Sub
• Number of Pins: 15
• Gender: Male (Plug)
• Termination Style: Solder Cup
• Mounting Type: Cable Mount
• Shell Size: DE-15
• Contact Plating: Gold Flash
• Contact Material: Copper Alloy
• Insulator Material: Thermoplastic (PBT)
• Shell Material: Steel, Nickel Plated
• Current Rating per Contact: 5 A
• Voltage Rating: 250 V
• Operating Temperature Range: -55°C to +105°C
• Mating Cycles: 50
• RoHS Compliant: Yes
• Product Series: EDS
• Application: Data, Signal Transmission
• Housing Type: Standard Profile

Recommendations

For optimal performance, use with matching D-Sub hoods and ensure proper soldering technique. Suitable for use with 28-20 AWG wires. Always verify compatibility with your device's connector layout.
