EFB Elektronik Duplex Patch Cable LC/LC Multi-Mode OM3 1m LSZH Aqua

The EFB Elektronik Duplex Patch Cable O0381.5 is a high-performance fiber optic patch cable designed for reliable data transmission in 10 Gigabit Ethernet networks. With LC to LC connectors and multi-mode OM3 fiber, this 1-meter cable ensures low insertion loss and high bandwidth, making it ideal for data centers, server rooms, and enterprise networks.

Advantages

Optimized for 10GbE applications, this cable offers excellent signal integrity with typical insertion loss <0.3 dB and return loss >30 dB. The LSZH (Low Smoke Zero Halogen) jacket ensures safety in enclosed spaces, reducing toxic fumes in case of fire. The aqua-colored jacket allows easy identification of OM3 fiber.

Suitable for

• 10 Gigabit Ethernet (10GbE) connections
• Data center patching and cross-connects
• Fiber optic network infrastructure
• High-speed server and storage area networks

Key specifications

• Connector Type: LC to LC Duplex
• Fiber Type: Multi-Mode OM3 (50/125 µm)
• Cable Length: 1 meter
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Jacket Color: Aqua
• Cable Diameter: 3.0 mm
• Insertion Loss: <0.3 dB typical
• Return Loss: >30 dB typical
• Operating Temperature: -20°C to +70°C
• Standards: IEC 60793-2-10 type A1a.2, TIA/EIA-492AAAC-B

Recommendations

For optimal performance, pair this patch cable with OM3-compatible transceivers and patch panels. Ensure clean connections and proper cable management to maintain signal quality.
