DELTA OVH-8D/SC Industrial 8-Channel RS-485/422 to Single-mode Fiber Optic Converter, SC Duplex, 20 km, DIN-Rail

In a sprawling industrial plant, multiple RS-485/422 devices—PLCs, meters, sensors—need to communicate with a central control room hundreds of meters away, where copper cabling is impractical and electromagnetic interference is high. The DELTA OVH-8D/SC solves this by converting eight independent RS-485/422 channels into a single-mode fiber optic link with SC duplex connectors, extending reliable data transmission up to 20 km.

Key specifications

• 8 independent RS-485/422 channels (screw terminal blocks)
• 1 fiber optic port: single-mode, SC duplex connector
• Transmission distance: up to 20 km
• Optical wavelength: 1310 nm
• RS-485/422 data rate: 0 – 115.2 Kbps, auto-detection
• Supports 2-wire RS-485 and 4-wire RS-422/485 modes
• Isolation: 1.5KV on RS-485/422 ports
• ESD protection: 15KV
• Power supply: DC 9-12V, consumption < 5W
• Operating temperature: -20°C to +70°C
• Metal housing, DIN-rail or wall-mount options

Why choose it

This rugged converter is built for demanding environments. Automatic data rate and direction control simplify setup, while LED indicators provide clear status for power, fiber link, and per-channel Tx/Rx activity. Its metal housing and flexible mounting options ensure easy integration into control cabinets.

Ideal use cases

• Building automation systems
• Traffic control systems
• Factory floor equipment networking
• Long-distance industrial data links

Good to know

The converter features 1.5KV isolation on each serial port, 15KV ESD protection, and a wide operating temperature range from -20°C to +70°C, making it suitable for harsh industrial environments.
