PLANET IGS-605HPT Industrial Gigabit Switch, 6 Ports, 4 PoE+, 240W, IP30, -40 to 75°C

Planet IGS-605HPT is a 6-port industrial unmanaged Gigabit switch with four Power-over-Ethernet Plus ports, engineered for extreme environments and high-bandwidth applications. It supplies up to 36W per PoE port with a total budget of 240W, enough to power heavy-duty IP cameras, outdoor wireless access points, and industrial IoT devices.

Advantages

Encased in an IP30-rated metal housing, this switch withstands dust, shocks, and temperature extremes from -40°C to 75°C. Redundant DC power inputs (48-54V) and 6KV surge/ESD protection guarantee uninterrupted operation in demanding sites, while the fanless design ensures silent, maintenance-free performance.

Suitable for

• Industrial Ethernet and automation networks
• IP surveillance systems, including PoE cameras
• Wireless access point and bridge installations
• Outdoor cabinets and roadside applications

Key specifications

• 6 x 10/100/1000BASE-T RJ45 ports, 4 with IEEE 802.3af/at PoE+
• PoE output up to 36W per port, 240W total budget
• Non-blocking switching capacity of 12 Gbps, forwarding rate 8.9 Mpps
• 8K MAC address table and 9K jumbo frame support
• Redundant 48-54V DC terminal block for power input
• Industrial IP30 metal case with DIN-rail and wall-mount design
• ESD and surge protection: 6KV DC
• Operating temperature: -40 to 75°C
• Unmanaged plug-and-play operation

Recommendations

For optimal PoE performance, pair the IGS-605HPT with a 54V DC power supply to achieve the full 240W power budget. This switch is an excellent choice for harsh outdoor and factory-floor environments where reliability and uptime are critical.
