DELTA LZ-6 Coaxial Power Injector Terminal Block for RG-6 Cable, F-Type Female, 12V DC, Black

For CCTV installers and antenna technicians, the DELTA LZ-6 coaxial power injector simplifies DC power delivery over RG-6 cable. This terminal block combines or separates DC power and RF/video signals, enabling remote powering of cameras, amplifiers, or modulators without extra wiring. Its screw terminals accept up to 18 AWG power cable, while the F-type female connector ensures a secure coaxial link.

Key specifications

• Product type: Coaxial power injector / terminal block
• Coaxial cable compatibility: RG-6
• Coaxial connection: F-type female
• Power input: 2 screw terminals (positive, negative)
• Max DC voltage: 12V DC
• Max DC current: 2A
• Housing material: High-impact plastic
• Terminal material: Nickel-plated brass
• Mounting: Inline / surface mountable
• Operating temperature: -10°C to +50°C
• Colour: Black

Why choose it

The LZ-6 streamlines installations by merging power and signal on a single coax run. Its robust plastic housing and nickel-plated brass terminals resist corrosion, ensuring long-term reliability. The compact design fits inline or mounts on surfaces, and the screw terminals provide a tool-free, secure connection for power wires.

Ideal use cases

• Powering CCTV cameras over RG-6 coaxial cable
• Injecting DC power into antenna systems or RF distribution networks
• Combining or separating power and video signals in surveillance setups
• DIY projects requiring DC power over coax with minimal wiring

Good to know

The LZ-6 is a passive device; it does not regulate voltage or provide surge protection. Ensure your power supply matches the 12V DC, 2A maximum rating. For outdoor use, protect the unit from direct moisture. The F-type connector is standard for RG-6 cables, but an adapter may be needed for other cable types.
