Computer Case ASRock 1U1G-W680/2L2T Rack (1U) Grey

Computer Case ASRock 1U1G-W680/2L2T Rack (1U) Grey
Computer Case ASRock 1U1G-W680/2L2T Rack (1U) Grey
Computer Case ASRock 1U1G-W680/2L2T Rack (1U) Grey
Computer Case ASRock 1U1G-W680/2L2T Rack (1U) Grey
Computer Case ASRock 1U1G-W680/2L2T Rack (1U) Grey
Computer Case ASRock 1U1G-W680/2L2T Rack (1U) Grey
Computer Case ASRock 1U1G-W680/2L2T Rack (1U) Grey
Computer Case ASRock 1U1G-W680/2L2T Rack (1U) Grey
Computer Case ASRock 1U1G-W680/2L2T Rack (1U) Grey
Computer Case ASRock 1U1G-W680/2L2T Rack (1U) Grey
R42,157
The ASRock 1U1G-W680/2L2T is a compact 1U rack-mount server chassis designed for high-performance computing in space-constrained environments. Built on the Intel W680 chipset with an LGA 1700 socket, it supports Intel processors and delivers robust connectivity and storage capabilities for enterpris... Read More
Stock 1 Code 1462536 Brand ASROCK Model 1U1G-W680/2L2T Warranty 2 Years

Shipping & Returns

Estimated delivery Tuesday, October 6
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

The ASRock 1U1G-W680/2L2T is a compact 1U rack-mount server chassis designed for high-performance computing in space-constrained environments. Built on the Intel W680 chipset with an LGA 1700 socket, it supports Intel processors and delivers robust connectivity and storage capabilities for enterprise or data center applications.

Key features

  • Supports DDR5-SDRAM memory with a maximum capacity of 192 GB and 1.1 V voltage
  • Accommodates 2.5-inch and M.2 storage drives, compatible with both HDD and SSD via PCI Express 3.0 and Serial ATA III interfaces
  • Integrated Aspeed AST2600 graphics controller for basic display output
  • Dual 10 Gigabit Ethernet and Gigabit Ethernet ports with Intel I210 and Intel X710 LAN controllers for high-speed networking
  • Hot-swap 2.5-inch drive bays for easy maintenance and scalability
  • 1U rack-mount form factor optimized for dense server installations
Key Highlights
  • High-density rack servers and edge computing nodes
  • Virtualisation hosts and small to medium enterprise workloads
  • Storage-focused builds using multiple 2.5" SSDs and M.2 drives
  • Network appliances requiring dual 10 GbE connectivity
  • Form factor: 1U rack-mount chassis
  • Chipset and socket: Intel W680 chipset with LGA 1700 socket
  • Memory support: DDR5-SDRAM up to 192 GB
  • Drive bays: four 2.5" bays
  • M.2 support: PCI Express 3.0 and SATA III interfaces for M.2 SSDs
  • Graphics: onboard Aspeed AST2600 remote-management graphics
  • Network: dual 10 Gigabit Ethernet ports
  • USB: two USB 2.0 ports and four USB 3.2 Gen 1 Type-A ports
  • Power: integrated 800 W power supply
  • Colour: grey
Specifications
80 PLUS certification
80 PLUS Platinum
AC input frequency
50/60
AC input voltage
100 - 240
BIOS type
AMI
Built-in processor
No
Chassis type
Rack (1U)
COM ports quantity
1
Depth
438 mm
DisplayPorts quantity
1
Ethernet interface type
10 Gigabit Ethernet, Gigabit Ethernet
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
4
HDMI ports quantity
1
Height
43.5 mm
Hot-swap HDD bays
Yes
Hot-swap PSU
Yes
IPMI LAN (RJ-45) port
Yes
LAN controller
Intel X710, Intel I210
LED indicators
Unit Identification (UID), Power, LAN, Fault, Activity
Maximum internal memory
192 GB
Memory voltage
1.1
Motherboard chipset
Intel W680
Number of 2.5" bays
4
Number of DIMM slots
4
Number of hot-swap PSUs supported
1
Number of main power supplies
2
Number of processors supported
1
Number of storage drives supported
5
On-board graphics card model
Aspeed AST2600
Operating relative humidity (H-H)
20 - 90
Operating temperature (T-T)
10 - 35
Optical drive type
No
PCI Express slots version
4.0
PCI Express x16 (Gen 4.x) slots
1
Plug and Play
Yes
Power supply
800 W
Processor manufacturer
Intel
Processor socket
LGA 1700
Product colour
Grey
Reset button
Yes
SSD form factor
M.2
Storage drive sizes supported
2.5, M.2
Storage temperature (T-T)
-40 - 70
Supported memory types
DDR5-SDRAM
Supported storage drive interfaces
PCI Express 3.0, Serial ATA III
Supported storage drive types
HDD & SSD
USB 2.0 ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
VGA (D-Sub) ports quantity
1
Width
650 mm
