BLUEOPTICS Extreme Networks EQPC1HPC050C0100 Compatible BlueLAN Direct Attach Cable (DAC) - Passive 100 Gigabit Twinaxial Copper, QSFP28 to QSFP28, 0.5m

The BLUEOPTICS Extreme Networks EQPC1HPC050C0100 Compatible BlueLAN Direct Attach Cable (DAC) is a high-performance, passive twinaxial copper cable designed for 100 Gigabit Ethernet connections. It features QSFP28 connectors on both ends, making it ideal for short-range interconnects within racks or between adjacent racks in data centers and enterprise networks. This cable is fully compatible with Extreme Networks equipment and offers reliable, low-latency connectivity for high-bandwidth applications.

Advantages

This DAC cable provides a cost-effective and energy-efficient solution for high-speed data transmission. With a power consumption of less than 0.5W per end, it minimizes heat generation and operational costs. The passive design ensures zero signal processing, resulting in ultra-low latency and high signal integrity. The 30 AWG construction offers flexibility for easy cable management, while the PVC jacket provides durability and protection.

Suitable for

• Data center interconnects (rack-to-rack, server-to-switch)
• High-performance computing (HPC) clusters
• Enterprise network backbone connections
• Storage area networks (SAN)
• Telecommunications equipment

Key specifications

• Product Type: Direct Attach Cable (DAC)
• Cable Type: Twinaxial Copper
• Data Rate: 100 Gigabit Ethernet
• Connector Type (End A): QSFP28
• Connector Type (End B): QSFP28
• Active/Passive: Passive
• Compatibility: Extreme Networks
• Compatible OEM Part Number: Extreme Networks EQPC1HPC050C0100
• Cable Length: 0.5 meters
• AWG: 30 AWG
• Protocol Support: IEEE 802.3bj (100GBASE-CR4), InfiniBand EDR/FDR
• Hot-Swappable: Yes
• RoHS Compliant: Yes
• Operating Temperature: 0°C to 70°C
• Storage Temperature: -40°C to 85°C
• Power Consumption: < 0.5W per end
• Impedance: 100 Ohm
• Jacket Material: PVC

Recommendations

For optimal performance, ensure that both connected devices support QSFP28 interfaces and 100GBASE-CR4 standards. This cable is plug-and-play and does not require any configuration. It is recommended for use in controlled environments within the specified temperature range.
