AXION CON-101 DC/DC Step-Down Power Converter 24V to 12V 10A 120W

The AXION CON-101 Power Converter is a high-efficiency DC/DC step-down converter designed to convert a nominal 24V DC input (range 18V-32V) to a stable 12V DC output. With a continuous output current of 10A and output power of 120W, it is ideal for industrial, automotive, and telecom applications where reliable voltage conversion is required.

Advantages

This converter offers over 90% efficiency, reducing energy loss and heat generation. Its compact aluminum housing with convection cooling ensures reliable operation without a fan. Built-in protection features (overload, short circuit, over-temperature, input reverse polarity) safeguard both the converter and connected equipment.

Suitable for

• Industrial control systems
• Automotive electronics
• Telecommunications equipment
• LED lighting installations
• Battery-powered systems requiring 12V from a 24V supply

Key specifications

• Converter Type: DC/DC Step-Down
• Input Voltage: 24V DC (18V-32V range)
• Output Voltage: 12V DC
• Output Current: 10A continuous
• Output Power: 120W
• Efficiency: >90%
• Voltage Regulation: ±1%
• Ripple & Noise: <100mVp-p
• Protection: Overload, Short Circuit, Over-temperature, Input Reverse Polarity
• Operating Temperature: -20°C to +50°C
• Connections: Screw Terminals
• Housing Material: Aluminum
• Cooling Method: Convection
• Mounting Type: Surface Mount (via mounting holes)
• No-load Current: <50mA

Recommendations

For best performance, ensure the input voltage is within the specified range and the load does not exceed 10A continuous. The converter is designed for surface mounting; use appropriate mounting holes for secure installation. Suitable for use in dry, well-ventilated areas.
