ASUS PRIME B840-PLUS WIFI AMD B840 Socket AM5 ATX

ASUS PRIME B840-PLUS WIFI AMD B840 Socket AM5 ATX
ASUS PRIME B840-PLUS WIFI AMD B840 Socket AM5 ATX
ASUS PRIME B840-PLUS WIFI AMD B840 Socket AM5 ATX
ASUS PRIME B840-PLUS WIFI AMD B840 Socket AM5 ATX
ASUS PRIME B840-PLUS WIFI AMD B840 Socket AM5 ATX
ASUS PRIME B840-PLUS WIFI AMD B840 Socket AM5 ATX
ASUS PRIME B840-PLUS WIFI AMD B840 Socket AM5 ATX
ASUS PRIME B840-PLUS WIFI AMD B840 Socket AM5 ATX
36 mo.
ASUS PRIME B840-PLUS WIFI AMD B840 Socket AM5 ATX
ASUS PRIME B840-PLUS WIFI AMD B840 Socket AM5 ATX
ASUS PRIME B840-PLUS WIFI AMD B840 Socket AM5 ATX
ASUS PRIME B840-PLUS WIFI AMD B840 Socket AM5 ATX
ASUS PRIME B840-PLUS WIFI AMD B840 Socket AM5 ATX
ASUS PRIME B840-PLUS WIFI AMD B840 Socket AM5 ATX
ASUS PRIME B840-PLUS WIFI AMD B840 Socket AM5 ATX
ASUS PRIME B840-PLUS WIFI AMD B840 Socket AM5 ATX
R2,961
B840-PLUS WIFIASUS Prime series motherboards are expertly engineered to unleash the full potential of AMD Ryzen™ 9000 series processors. The PRIME B840-PLUS WIFI motherboard provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features. It’... Read More
Stock 62 Code 105695 Brand ASUS Model 90MB1IZ0-M0EAY0 Warranty 3 Years

Shipping & Returns

Estimated delivery Wednesday, October 7
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival
B840-PLUS WIFI
ASUS Prime series motherboards are expertly engineered to unleash the full potential of AMD Ryzen™ 9000 series processors. The PRIME B840-PLUS WIFI motherboard provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features. It’s designed to be Advanced AI PC-ready, offering the power and connectivity needed for demanding AI applications.

ASUS PRIME B840-PLUS WIFI. Processor manufacturer: AMD, Processor socket: Socket AM5, Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series. Supported memory types: DDR5-SDRAM, Maximum internal memory: 192 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Ethernet interface type: 2.5 Gigabit Ethernet, Top Wi-Fi standard: Wi-Fi 6E (802.11ax), Wi-Fi standards: Wi-Fi 6E (802.11ax). Component for: PC, Motherboard form factor: ATX, Motherboard chipset family: AMD

Key Highlights
  • AMD Socket AM5 AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
  • PC ATX AMD B840 7.1 channels
  • DDR5-SDRAM 4 DIMM Maximum internal memory: 192 GB
  • HDD & SSD M.2, SATA III RAID support Number of storage drives supported: 7
  • BIOS type: UEFI AMI 256 Mbit
  • 2.5 Gigabit Ethernet Wi-Fi Wi-Fi 6E (802.11ax) Bluetooth 5.3
Specifications
12V power connector
Yes
1st M.2 highest PCI Express generation
4.0
1st M.2 largest key size
2280
2nd M.2 highest PCI Express generation
4.0
2nd M.2 largest key size
2280
3rd M.2 highest PCI Express generation
3.0
3rd M.2 largest key size
2280
Antenna included
Yes
ATX Power connector (24-pin)
Yes
Audio output channels
7.1 channels
BIOS memory size
256 Mbit
BIOS type
UEFI AMI
Bluetooth
Yes
Bluetooth version
5.3
Cables included
SATA
Chassis intrusion connector
Yes
Compatible processor series
AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Component for
PC
CPU fan connector
Yes
Depth
244 mm
DisplayPorts quantity
1
DVI-D ports quantity
0
ECC сompatibility
ECC & Non-ECC
Ethernet interface type
2.5 Gigabit Ethernet
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Front panel audio connector
Yes
HDMI ports quantity
1
Maximum internal memory
256 GB
Memory channels
Dual-channel
Memory slots type
DIMM
Motherboard chipset
AMD B840
Motherboard chipset family
AMD
Motherboard form factor
ATX
mSATA ports quantity
0
Number of chassis fan connectors
4
Number of COM connectors
1
Number of HDDs supported
4
Number of M.2 (M) slots
3
Number of memory slots
4
Number of SATA connectors
0
Number of SATA II connectors
0
Number of SATA III connectors
4
Number of storage drives supported
7
On-board graphics card
No
Package depth
273 mm
Package height
68 mm
Package weight
1.26 kg
Package width
353 mm
Parallel processing technology support
Not supported
PCI Express x1 (Gen 3.x) slots
1
PCI Express x16 (Gen 3.x) slots
3
PCI Express x16 (Gen 4.x) slots
1
Processor manufacturer
AMD
Processor socket
Socket AM5
Product colour
Aluminium, Black
RAID levels
0, 1, 5, 10
RAID support
Yes
S/PDIF out connector
Yes
Screws included
Yes
Supported memory types
DDR5-SDRAM
Supported processor sockets
Socket AM5
Supported storage drive interfaces
M.2, SATA III
Supported storage drive types
HDD & SSD
Thunderbolt headers
1
Top Wi-Fi standard
Wi-Fi 6E (802.11ax)
TPM connector
Yes
Unbuffered memory
Yes
USB 2.0 connectors
2
USB 2.0 ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) connectors
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
VGA (D-Sub) ports quantity
0
Wi-Fi
Yes
Wi-Fi standards
Wi-Fi 6E (802.11ax)
Width
305 mm
WiFi-AP antenna jack
1
Windows operating systems supported
Windows 10 x64, Windows 11
