Motherboard ASRock B450 PRO4 R2.0 AMD B450 Socket AM4 ATX

Motherboard ASRock B450 PRO4 R2.0 AMD B450 Socket AM4 ATX
Motherboard ASRock B450 PRO4 R2.0 AMD B450 Socket AM4 ATX
Motherboard ASRock B450 PRO4 R2.0 AMD B450 Socket AM4 ATX
Motherboard ASRock B450 PRO4 R2.0 AMD B450 Socket AM4 ATX
Motherboard ASRock B450 PRO4 R2.0 AMD B450 Socket AM4 ATX
36 mo.
Motherboard ASRock B450 PRO4 R2.0 AMD B450 Socket AM4 ATX
Motherboard ASRock B450 PRO4 R2.0 AMD B450 Socket AM4 ATX
Motherboard ASRock B450 PRO4 R2.0 AMD B450 Socket AM4 ATX
Motherboard ASRock B450 PRO4 R2.0 AMD B450 Socket AM4 ATX
Motherboard ASRock B450 PRO4 R2.0 AMD B450 Socket AM4 ATX
R1,887
The ASRock B450 PRO4 R2.0 is a reliable ATX motherboard built on the AMD B450 chipset, supporting Socket AM4 for a wide range of AMD Ryzen processors. It offers a balanced mix of performance, connectivity, and expandability for mainstream desktop builds.Key features Socket AM4 compatible with AMD Ry... Read More
Stock Out Of StockNo Stock Code 10427 Brand ASROCK Model B450 PRO4 R2.0 Warranty 3 Years

Shipping & Returns

The ASRock B450 PRO4 R2.0 is a reliable ATX motherboard built on the AMD B450 chipset, supporting Socket AM4 for a wide range of AMD Ryzen processors. It offers a balanced mix of performance, connectivity, and expandability for mainstream desktop builds.

Key features

  • Socket AM4 compatible with AMD Ryzen 3000, 4000 G-Series, and 5000 Series processors (BIOS update may be required)
  • 4 x DDR4 memory slots supporting up to 128 GB with frequencies up to 3200 MHz (OC)
  • 2 x PCIe 3.0 x16 slots for graphics cards and 4 x PCIe 2.0 x1 slots for expansion
  • 6 x SATA III ports for storage devices, plus 2 x M.2 sockets for ultra-fast SSDs
  • Rear I/O includes 1 x USB 3.2 Gen2 Type-C, 1 x USB 3.2 Gen2, 4 x USB 3.2 Gen1, 2 x USB 2.0, HDMI, DisplayPort, D-Sub, and Gigabit LAN
  • Onboard 8-channel HD Audio for immersive sound
  • Supports RAID configurations for data redundancy or performance
Key Highlights
  • Building a mainstream AMD-based desktop with Ryzen or Athlon CPUs
  • Systems that need multiple displays without a dedicated GPU (requires CPU with integrated graphics)
  • Users who want fast storage: NVMe M.2 SSD plus SATA devices
  • Enthusiasts planning moderate overclocking and system tuning
  • Form factor: ATX
  • Chipset: AMD B450
  • CPU socket: Socket AM4 (supports Ryzen 3000/5000 and Athlon)
  • Memory: 4 × DDR4 DIMM slots, up to 128 GB
  • PCI Express: 2 × PCIe x16 (Gen3), additional PCIe slots
  • Storage: Dual M.2 (one PCIe Gen3 x4, one PCIe Gen3 x2/SATA), SATA III ports, RAID 0/1/10
  • USB: Dual USB 3.2 Gen2 (Type-A + Type-C) on rear I/O
  • LAN: Realtek RTL8111H Gigabit Ethernet
  • Audio & video: D-Sub, DisplayPort, HDMI (HDMI supports 4K; integrated GPU required)
  • Special features: 10-phase power design, 2oz copper PCB, Solid capacitors, Full Spike Protection, A-Tuning
Specifications
12V power connector
Yes
ACPI version
5.1
ATX Power connector (24-pin)
Yes
Audio chip
Realtek ALC892 / Realtek ALC897
Audio output channels
7.1
BIOS memory size
128 Mbit
BIOS type
UEFI AMI
Bundled software
ASRock A-Tuning ASRock Polychrome SYNC ASRock XFast LAN
Cables included
SATA
Certification
FCC, CE ErP/EuP
Compatible processor series
AMD Athlon
Component for
PC
CPU fan connector
Yes
Depth
224 mm
DirectX version
12.0
DisplayPort version
1.2
DisplayPorts quantity
1
Drivers included
Yes
DVI-D ports quantity
0
ECC сompatibility
ECC & non-ECC
Ethernet interface type
Gigabit Ethernet
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Front panel audio connector
Yes
Harmonized System (HS) code
84733020
HDCP
Yes
HDMI ports quantity
1
HDMI version
1.4
LAN controller
Realtek RTL8111H
Maximum internal memory
128 GB
Maximum number of SMP processors
1
Maximum resolution
4096 x 2160
Memory channels
Dual-channel
Memory slots type
DIMM
Motherboard chipset
AMD B450
Motherboard chipset family
AMD
Motherboard form factor
ATX
Number of chassis fan connectors
3
Number of COM connectors
1
Number of displays supported
3
Number of M.2 (M) slots
2
Number of memory slots
4
Number of SATA III connectors
6
Parallel processing technology support
Quad-GPU CrossFireX, CrossFireX
PC health monitoring
Voltage, Temperature, FAN
PCI Express x1 (Gen 2.x) slots
4
PCI Express x16 (Gen 3.x) slots
2
Processor manufacturer
AMD
Processor socket
Socket AM4
PS/2 ports quantity
1
RAID levels
10, 1
RAID support
Yes
RGB LED pin header
Yes
Supported memory clock speeds
2933, 2667, 3200, 2400, 2133
Supported memory types
DDR4-SDRAM
Supported storage drive interfaces
M.2, SATA III
System Management BIOS (SMBIOS) version
2.3
TPM connector
Yes
Unbuffered memory
Yes
USB 2.0 connectors
2
USB 2.0 ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
VGA (D-Sub) ports quantity
1
Wake-on-LAN ready
Yes
Wi-Fi
No
Width
305 mm
Windows operating systems supported
Windows 10 x64

Leaflet

Open Leaflet
Price history over the last 6 months
Motherboard ASRock B450 PRO4 R2.0 AMD B450 Socket AM4 ATX
Current
R1,887
Lowest
R1,619
Highest
R2,012
Change 24H
+R111   +6%
Week
+R198   +12%
Month
+R187   +11%
