MSI MAG B760 TOMAHAWK WIFI motherboard LGA 1700 ATX

MSI MAG B760 TOMAHAWK WIFI motherboard LGA 1700 ATX
MSI MAG B760 TOMAHAWK WIFI motherboard LGA 1700 ATX
MSI MAG B760 TOMAHAWK WIFI motherboard LGA 1700 ATX
MSI MAG B760 TOMAHAWK WIFI motherboard LGA 1700 ATX
MSI MAG B760 TOMAHAWK WIFI motherboard LGA 1700 ATX
36 mo.
MSI MAG B760 TOMAHAWK WIFI motherboard LGA 1700 ATX
MSI MAG B760 TOMAHAWK WIFI motherboard LGA 1700 ATX
MSI MAG B760 TOMAHAWK WIFI motherboard LGA 1700 ATX
MSI MAG B760 TOMAHAWK WIFI motherboard LGA 1700 ATX
MSI MAG B760 TOMAHAWK WIFI motherboard LGA 1700 ATX
R3,677
unite as oneThe MAG series fights alongside gamers in pursuit of honor.With added military-inspired elements in these gaming products, they were reborn as the symbol of sturdiness and durability.Extended HeatsinkExtended Heatsink enlarges the surface of heat dissipation, ensuring even high-end proce... Read More
Stock 5 Code 28166 Brand MSI Model MAG B760 TOMAHAWK WIFI Warranty 3 Years

Shipping & Returns

Estimated delivery Tuesday, September 29
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival
unite as one
The MAG series fights alongside gamers in pursuit of honor.
With added military-inspired elements in these gaming products, they were reborn as the symbol of sturdiness and durability.

Extended Heatsink
Extended Heatsink enlarges the surface of heat dissipation, ensuring even high-end processors to run in full speed.

M.2 Shield Frozr
Keeps M.2 SSDs safe while preventing throttling, making them run faster.

Heavy Plated VRM Heatsink
The VRM heatsink covers the upper
MOS and helps dissipate the heat.

7W/mK Thermal Pad &
Additional Choke Pad
High quality 7W/mK MOSFET thermal pads and extra choke thermal pads ensure all cores running in high performcance.

LIGHTNING GEN 5 PCI-E
Doubling over the previous generation, the bandwidth of a x16 interface can reach 128GB/s.

SMT PCIE 5.0 SLOT
The advanced SMT(Surface Mount Technology) PCIE slot diminish interference and electrical noise, fully support the PCI-E 5.0 signal.

REINFORCED,
HEAVY SOLDERED CONNECTIONS
Secure to the motherboard with extra solder points and support the weight of heavy graphics cards.

MSI MAG B760 TOMAHAWK WIFI. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processor series: Intel® Celeron®, Intel® Pentium® Gold. Supported memory types: DDR5-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, RAID levels: 0, 1, 5, 10. Ethernet interface type: 2.5 Gigabit Ethernet, Top Wi-Fi standard: Wi-Fi 6E (802.11ax), Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E.... Component for: PC, Motherboard form factor: ATX, Motherboard chipset family: Intel

Key Highlights
  • Supports 12th/ 13th Gen Intel® Core™, Pentium® Gold and Celeron® processors for LGA 1700 socket
  • Supports DDR5 Memory, up to 7000+(OC) MHz
  • Enhanced Power Design: 12+1+1 Duet Rail Power System, dual 8-pin CPU power connectors, Core Boost, Memory Boost
  • Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 4 x4 M.2, USB 3.2 Gen 2x2
  • Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works
  • AUDIO BOOST: Reward your ears with studio grade sound quality for the most immersive gaming experience
  • High Quality PCB: 6-layer PCB made by 2oz thickened copper and server grade level material
  • Intel LGA 1700 Intel® Celeron®, Intel® Pentium® Gold
  • PC ATX Realtek ALC897 7.1 channels
  • DDR5-SDRAM 4 DIMM Maximum internal memory: 128 GB
  • M.2, SATA III RAID support
  • BIOS type: UEFI AMI 256 Mbit ACPI version: 6.4
  • 2.5 Gigabit Ethernet Wi-Fi Wi-Fi 6E (802.11ax) Bluetooth 5.3
Specifications
ACPI version
6.4
ATX Power connector (24-pin)
Yes
Audio chip
Realtek ALC897
Audio output channels
7.1 channels
BIOS memory size
256 Mbit
BIOS type
UEFI AMI
Bluetooth
Yes
Bluetooth version
5.3
Compatible processor series
Intel® Celeron®, Intel® Pentium® Gold
Component for
PC
CPU fan connector
Yes
Depth
304.8 mm
DisplayPort version
1.4
DisplayPorts quantity
1
DVI-D ports quantity
0
ECC сompatibility
Non-ECC
Ethernet interface type
2.5 Gigabit Ethernet
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Front panel audio connector
Yes
Front panel connector
Yes
HDMI ports quantity
1
HDMI version
2.1
Maximum internal memory
128 GB
Maximum number of SMP processors
1
Memory channels
Dual-channel
Memory slots type
DIMM
Motherboard chipset family
Intel
Motherboard form factor
ATX
mSATA ports quantity
0
Number of M.2 (M) slots
3
Number of memory slots
4
Number of SATA connectors
0
Number of SATA II connectors
0
Number of SATA III connectors
4
On-board graphics card
No
PCI Express x1 (Gen 3.x) slots
1
PCI Express x16 slots
2
Power source type
ATX
Processor manufacturer
Intel
Processor socket
LGA 1700
Product colour
Black
RAID levels
0, 1, 5, 10
RAID support
Yes
RGB LED pin header
Yes
S/PDIF out connector
Yes
Supported memory clock speed (max)
7000 MHz
Supported memory clock speeds
7000, 6800, 6600, 6400, 6200, 6000, 5800, 5600, 5400, 5200, 5000, 4800 MHz
Supported memory types
DDR5-SDRAM
Supported processor sockets
LGA 1700
Supported storage drive interfaces
M.2, SATA III
System Management BIOS (SMBIOS) version
3.5
Top Wi-Fi standard
Wi-Fi 6E (802.11ax)
TPM connector
Yes
USB 2.0 connectors
4
USB 2.0 ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) connectors
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) connectors
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
USB 3.2 Gen 2x2 Type-C ports quantity
1
VGA (D-Sub) ports quantity
0
Wi-Fi
Yes
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Width
243.8 mm
Windows operating systems supported
Windows 10, Windows 11

Manual

Open Manual

Leaflet

Open Leaflet
