ARCTIC BioniX P120 (White) – Pressure-optimised 120 mm Gaming Fan with PWM PST

ARCTIC BioniX P120 (White) – Pressure-optimised 120 mm Gaming Fan with PWM PST
ARCTIC BioniX P120 (White) – Pressure-optimised 120 mm Gaming Fan with PWM PST
ARCTIC BioniX P120 (White) – Pressure-optimised 120 mm Gaming Fan with PWM PST
ARCTIC BioniX P120 (White) – Pressure-optimised 120 mm Gaming Fan with PWM PST
ARCTIC BioniX P120 (White) – Pressure-optimised 120 mm Gaming Fan with PWM PST
ARCTIC BioniX P120 (White) – Pressure-optimised 120 mm Gaming Fan with PWM PST
ARCTIC BioniX P120 (White) – Pressure-optimised 120 mm Gaming Fan with PWM PST
ARCTIC BioniX P120 (White) – Pressure-optimised 120 mm Gaming Fan with PWM PST
ARCTIC BioniX P120 (White) – Pressure-optimised 120 mm Gaming Fan with PWM PST
ARCTIC BioniX P120 (White) – Pressure-optimised 120 mm Gaming Fan with PWM PST
ARCTIC BioniX P120 (White) – Pressure-optimised 120 mm Gaming Fan with PWM PST
ARCTIC BioniX P120 (White) – Pressure-optimised 120 mm Gaming Fan with PWM PST
ARCTIC BioniX P120 (White) – Pressure-optimised 120 mm Gaming Fan with PWM PST
ARCTIC BioniX P120 (White) – Pressure-optimised 120 mm Gaming Fan with PWM PST
R326
The BioniX P120 fan features completely redesigned fanblades and is optimised for high static pressure. Thus, the BioniX P120 is especially effective when used on heatsinks and with higher air resistance.The wide RPM range from 200 to 2100 RPM can be regulated seamlessly and synchronously with other... Read More
Stock 2 Code 115643 Brand ARCTIC Model ACFAN00116A Warranty 2 Years

Shipping & Returns

Estimated delivery Tuesday, September 29
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival
The BioniX P120 fan features completely redesigned fanblades and is optimised for high static pressure. Thus, the BioniX P120 is especially effective when used on heatsinks and with higher air resistance.
The wide RPM range from 200 to 2100 RPM can be regulated seamlessly and synchronously with other fans thanks to ARCTIC's PWM Sharing Technology (PST).
The newly developed motor with a low coil temperature significantly increases the life span of the fan. Therefore we have extended the warranty to 10 years.
Optimised for Static Pressure

Optimised for Static Pressure

During the development of the new BioniX P120, special emphasis was placed on a focused airstream and thus a high static pressure. The fan guarantees extremely efficient cooling, even with increased air resistance. Therefore, the BioniX P120 is particularly suitable for use on heatsinks and radiators.

More Efficient Technology

The motor is powered by a Neodym-Iron-Boron-Magnet ring of the newest generation, which allows the new BioniX P120 to run much more efficiently than its predecessors. This saves energy and lowers the coil temperature without comprimising the performance.
More Efficient Technology
Maximum Quietness, Minimum Vibration

Maximum Quietness, Minimum Vibration

Even at low speeds the operating sound of the new ARCTIC motor is barely noticeable.Due to a sinus-magnetizing the new motor only creates about 5 % of the vibration from commutation of a regular DC-motor without filter. Consequently, there is no need for rubber spacers due to the steady and smooth torque of the new motor.

Extended Life Span

A 10 °C lower motor temperature roughly doubles the life span of a fan. The new ARCTIC motor has a four times longer service life through its low coil temperature. Consequently, we have extended the warranty to 10 years.
Extended Life Span
200 to 2100 RPM regulated via PWM PST

200 to 2100 RPM regulated via PWM PST

With a wide range of regulation and the PWM Sharing Technology (PST), the BioniX P120 fan speed can be controlled synchronously with all your other fans together. This keeps noise at a minimum while guaranteeing maximum cooling performance when needed.

High Quality Bearing

Thanks to an alloy/lubricant combination developed in Germany, friction within the bearing is reduced and greater efficiency is achieved. As a result, there is less heat development as well as less bearing noise, which means you can enjoy a longer service life from your fan.
High Quality Bearing
Strong Cooling Performance

Strong Cooling Performance

Numerous improvements, such as an updated engine technology and a newly developed fan design, have noticeably increased the performance of P-fans. In internal performance tests leveled to 28 dB (A), the new P-fans left many competitors behind.
Key Highlights
  • Optimised for static pressure
  • Ideal choice on heatsinks, radiators and (partly-) covered case vents
  • Broad RPM range for highest performance and low noise level
  • Push- or pull-configuration
  • PWM Sharing Technology (PST) regulates fan speed synchronously
  • Newly developed, very quiet motor
  • Extended life span
  • Available in multiple distinct colors
  • Computer case Fan 12 cm 2100 RPM
  • 25.5 dB 67.56 cfm Fluid Dynamic Bearing (FDB)
  • Pulse-width modulation (PWM) support
  • Black, White
Specifications
Airflow
114.79 m³/h
Bearing type
Fluid Dynamic Bearing (FDB)
Cable length
0.4 m
Compatible processor series
Not supported
Compliance certificates
RoHS
Country of origin
China
Depth
120 mm
Fan connector
4-pin + 4-pin
Fan diameter
12 cm
Harmonized System (HS) code
84733080
Height
27 mm
Maximum airflow
67.56 cfm
Mounting hole pattern (W x D)
105 x 105 mm
Noise level
0.45 sone
Noise level (high speed)
25.5 dB
Number of fan blades
5
Number of fans
1 fan(s)
Number of screws
4
Package depth
125 mm
Package height
34 mm
Package type
Box
Package weight
175 g
Package width
130 mm
Power consumption (typical)
1.56 W
Product colour
Black, White
Pulse-width modulation (PWM) support
Yes
Rated current
0.13 A
Rotational speed (max)
2100 RPM
Rotational speed (min)
200 RPM
Screws included
Yes
Suitable location
Computer case
Supported processor sockets
Not supported
Type
Fan
Voltage
12 V
Weight
140 g
Width
120 mm
