ACT 80m Singlemode OS2 Indoor/Outdoor Fiber Optic Cable, 8 Fibers, LC to LC, Yellow RL4108

Long-distance, high-bandwidth fiber optic links often suffer from signal loss and environmental vulnerability when using inferior cabling. The ACT RL4108 80-meter singlemode OS2 cable with 8 fibers and pre-terminated LC connectors solves this by delivering a robust, low-loss, indoor/outdoor solution ready for immediate deployment.

Who is it for

Network installers, data center technicians, and enterprise IT teams needing a reliable, pre-terminated multi-fiber trunk for backbone or horizontal runs. Ideal for connecting switches, patch panels, or media converters in campus or building environments where durability and performance are critical.

Main features

• 80-meter singlemode OS2 fiber, 9/125 µm core/cladding, supports 1G to 100G Ethernet and Fibre Channel.
• 8 individual LC connectors on each end for high-density patching and easy polarity management.
• Indoor/outdoor rated jacket: UV-resistant, robust LSZH/PE blend for versatile installation.
• Low insertion loss (≤0.3 dB per connector) and high return loss (≥50 dB) ensure signal integrity.
• Yellow jacket for quick identification as singlemode.
• Compliant with TIA/EIA-568-C.3 and RoHS.

Specifications

• Fiber type: Singlemode OS2 (ITU-T G.652.D or G.657.A1/A2)
• Fiber count: 8
• Connector type: LC to LC (8 connectors each end)
• Cable length: 80 meters
• Jacket color: Yellow
• Jacket material: LSZH/PE blend, UV-resistant
• Insertion loss: ≤0.3 dB per connector (typical)
• Return loss: ≥50 dB (typical)
• Application: Indoor/outdoor
• Compliance: RoHS, TIA/EIA-568-C.3

Tips

For best performance, avoid bending beyond the minimum bend radius and use proper cable management. Test each fiber with an OTDR or light source/power meter after installation to verify continuity and loss budgets.
