WAGO 750-626 2-Channel Digital Input Module 24 VDC, CAGE CLAMP, Light Gray

The WAGO 750-626 is a 2-channel digital input module designed for use with WAGO's 750 Series fieldbus couplers and controllers. It features CAGE CLAMP® connection technology for fast, reliable wiring of solid or fine-stranded conductors from 0.08 to 2.5 mm² (28–14 AWG). The module accepts 24 VDC nominal input voltage and provides binary signal detection with adjustable input delay. Its compact housing mounts on a standard 35 mm DIN rail and is rated IP20 for use in control cabinets.

Advantages

• CAGE CLAMP® spring pressure connection eliminates the need for tools, reducing installation time.
• Two independent digital inputs allow monitoring of two separate binary signals.
• Wide operating temperature range from 0°C to +55°C ensures reliable performance in industrial environments.
• 500 V system/field isolation protects against voltage transients.

Suitable for

• Industrial automation and control systems
• Building automation (HVAC, lighting, shading)
• Process control and monitoring
• Machine building and manufacturing

Key specifications

• Number of inputs: 2 (digital, binary)
• Nominal input voltage: 24 VDC
• Input current: 3 mA per channel typical
• Signal voltage '0': -3 V to +5 V
• Signal voltage '1': +15 V to +30 V
• Input delay: 3 ms (default)
• Connection: CAGE CLAMP®
• Conductor cross-section: 0.08–2.5 mm² (solid/fine-stranded)
• Mounting: DIN-rail 35 mm
• Operating temperature: 0°C to +55°C
• Storage temperature: -25°C to +85°C
• Protection class: IP20
• Isolation: 500 V system/field
• Internal current consumption: 15 mA
• Bit width: 2 bits
• Color: Light gray

Recommendations

For optimal performance, use with WAGO 750 Series bus couplers or controllers. Ensure proper DIN rail grounding and observe the specified conductor cross-sections. The module is suitable for use in dry, indoor environments only.
