WAGO 750-601 Digital Output Module 24VDC 2-Channel M12 IP20

With a compact 12 mm width and a robust 6.3 A system feed-through, the WAGO 750-601 delivers reliable 24 VDC digital outputs in a space-saving DIN-rail module. This 2-channel output module features M12 female connectors and per-channel LEDs, making it ideal for decentralized automation in tight control cabinets.

Overview

The WAGO 750-601 is a digital output module for the WAGO I/O System 750. It provides two 24 VDC outputs, each rated at 0.5 A, with a total module current of 1 A. The module connects via two 3-wire M12 female connectors (A-coded), ensuring secure and quick installation. No configuration is required—simply plug it into the fieldbus node and it is ready to operate.

What stands out

• Ultra-compact 12 mm width saves valuable DIN-rail space.
• High system feed-through current of 6.3 A for power distribution.
• M12 connectors provide vibration-resistant and IP67-rated field connections.
• LED status indicators per channel for quick diagnostics.
• Wide operating temperature range from 0 to +55 °C.
• Galvanic isolation of 500 V between system and field.

Technical details

• Module type: Digital output module
• Number of outputs: 2
• Output voltage: 24 VDC
• Output current per channel: 0.5 A
• Total output current: 1 A
• Connection type: 2 x M12 female, A-coded
• Wiring type: 3-wire
• Isolation: 500 V system/field
• System current consumption: 10 mA (from 24 VDC)
• Operating temperature: 0 to +55 °C
• Storage temperature: -25 to +85 °C
• Relative humidity: 0 to 95 % (non-condensing)
• Mounting type: DIN-rail
• Protection class: IP20
• Housing material: Polycarbonate, Polyamide 6.6
• Status display: LED per channel
• System compatibility: WAGO I/O System 750
• Configuration: None required

Our verdict

The WAGO 750-601 is a dependable choice for adding digital outputs to your WAGO I/O system. Its compact size, M12 connectivity, and high feed-through current make it a practical solution for machine builders and system integrators.
