WAGO 750-515 Digital Output Module, 2-Channel, 24 VDC, 0.5 A, CAGE CLAMP

The WAGO 750-515 is a digital output module for the WAGO I/O System 750, providing two sourcing outputs with 24 VDC and 0.5 A per channel. It features CAGE CLAMP® connection technology for secure and maintenance-free wiring, short-circuit and overload protection, and is designed for DIN-rail mounting. Ideal for industrial automation and control applications.

Advantages

Reliable digital output module with robust protection features, easy installation via CAGE CLAMP® connectors, and compact design for space-saving DIN-rail mounting. Compatible with the entire WAGO I/O System 750.

Suitable for

• Industrial automation and control systems
• PLC and distributed I/O applications
• Switching of actuators, indicators, and small loads

Key specifications

• Number of digital outputs: 2
• Output type: Digital, sourcing
• Output voltage: 24 VDC
• Output current per channel: 0.5 A
• Total output current: 1 A
• Short-circuit protection: Yes
• Overload protection: Yes
• Connection technology: CAGE CLAMP®
• Wiring type: 2-wire
• Isolation: Channel-to-internal bus
• Mounting type: DIN-rail
• Operating temperature: 0 ... 55 °C
• Storage temperature: -25 ... 85 °C
• Relative humidity: 95 % (non-condensing)
• Degree of protection: IP20
• Housing material: Polycarbonate, polyamide 6.6
• System compatibility: WAGO I/O System 750

Recommendations

For optimal performance, use with WAGO I/O System 750 bus couplers and power supplies. Ensure proper DIN-rail grounding and observe environmental limits.
