WAGO 222-505 5-Conductor Compact Splicing Connector, 0.08-4 mm², Transparent/Orange

The WAGO 222-505 is a compact 5-conductor splicing connector from the renowned 222 Series, featuring innovative lever-actuated CAGE CLAMP® technology for fast, tool-free wiring. Ideal for solid, stranded, and fine-stranded conductors from 0.08 to 4 mm² (28–12 AWG), this transparent/orange connector provides reliable, maintenance-free connections in junction boxes, lighting fixtures, and control cabinets.

Advantages

Lever actuation enables quick and easy installation without special tools. The transparent housing allows visual inspection of conductor insertion depth. Rated for 400 V / 32 A, it meets stringent safety standards (ENEC, UL, CSA, VDE). Compact design saves space in crowded enclosures.

Suitable for

• Electrical installations in residential and commercial buildings
• Lighting and switchgear connections
• Control cabinet wiring
• Repair and maintenance of electrical systems

Key specifications

• Number of conductors: 5
• Connection technology: CAGE CLAMP®
• Rated voltage: 400 V (EN)
• Rated current: 32 A (EN)
• Conductor cross-section: 0.08–4 mm² (28–12 AWG)
• Stripping length: 9–10 mm
• Color: Transparent / Orange
• Housing material: Polycarbonate (PC)
• Contact material: Copper
• Flammability rating: UL 94 V-2
• Operating temperature: -20 °C to +85 °C
• Weight: 5.4 g
• Dimensions: 67.5 x 52 x 4 mm

Recommendations

For best results, use with WAGO 222-500 series accessories and ensure conductors are properly stripped to 9–10 mm. Always follow local electrical codes and safety regulations.
