WAGO 2007-8876 EPSITRON ECO 120W DIN Rail Power Supply 24VDC 5A

The WAGO 2007-8876 is a high-efficiency DIN rail power supply from the EPSITRON® ECO 2007 Series, delivering 120W of reliable power with 24VDC output at 5A. Designed for industrial automation and control systems, this compact unit features push-in CAGE CLAMP® technology for fast, tool-free wiring and offers robust protection against overload and short circuits.

Advantages

With a typical efficiency of 89%, the WAGO 2007-8876 minimizes energy loss and heat generation, ensuring long service life and stable operation even in demanding environments. Its wide input voltage range (100-240VAC) and global frequency compatibility (50-60Hz) make it suitable for use worldwide. The IP20 protection rating and polycarbonate housing provide durability in clean, dry industrial settings.

Suitable for

• Industrial automation and process control systems
• Building automation (HVAC, lighting, security)
• Machine control cabinets and panel building
• IoT gateways and edge computing devices

Key specifications

• Input Voltage: 100-240 VAC
• Output Voltage: 24 VDC
• Output Current: 5 A
• Rated Power: 120 W
• Efficiency: Typ. 89%
• Mounting: DIN Rail
• Connection: Push-in CAGE CLAMP®
• Operating Temperature: -25 to +70 °C
• Dimensions (WxHxD): 85 x 99.6 x 65.3 mm
• Weight: 0.2 kg

Recommendations

For optimal performance, pair this power supply with WAGO's DIN rail accessories and use appropriate fusing on the input side. Ensure adequate ventilation and avoid mounting near heat sources.
