WAGO 2002-7114 2-Conductor Push-in Terminal Block, 2.5 mm², 800 V, Gray

The WAGO 2002-7114 is a high-quality 2-conductor terminal block from the 2002 Series, featuring the innovative Push-in CAGE CLAMP® connection technology. Designed for reliable and tool-free wiring, this terminal block is ideal for use in industrial control cabinets, building automation, and electrical installations. With a compact design and robust construction, it ensures secure connections for solid and fine-stranded conductors up to 4 mm² (12 AWG). Rated for 800 V and 24 A, it meets the demands of modern electrical systems.

Advantages

Tool-free Push-in connection saves installation time and reduces labor costs. Vibration-proof and maintenance-free connections ensure long-term reliability. Compact size allows for high-density wiring on DIN-rail 35 x 15 or 35 x 7.5 mm. Clear marking and color coding simplify identification and troubleshooting.

Suitable for

• Industrial control panels and switchgear
• Building automation and lighting control
• Machine building and process automation
• Power distribution and signal wiring

Key specifications

• Connection Technology: Push-in CAGE CLAMP®
• Number of Conductors: 2
• Nominal Cross-Section: 2.5 mm²
• Conductor Size (Solid): 0.25 - 4 mm² (22 - 12 AWG)
• Conductor Size (Fine-Stranded): 0.25 - 4 mm² (22 - 12 AWG)
• Nominal Voltage (IEC): 800 V
• Nominal Current (IEC): 24 A
• Rated Surge Voltage: 8 kV
• Mounting Type: DIN-rail 35 x 15 / 35 x 7.5
• Color: Gray
• Insulating Material: Polyamide (PA 66)
• Flammability Rating: UL 94 V-0
• Pollution Degree: 3
• Operating Temperature: -35 to +85 °C
• Stripping Length: 9 - 11 mm
• Wiring Type: Front-entry
• Number of Potentials: 1
• Approvals: VDE, UL, CSA, EAC

Recommendations

For optimal performance, use with WAGO marking strips and tools. Ensure proper stripping length (9-11 mm) for reliable connections. Suitable for use in environments with pollution degree 3.
