Victron Energy Orion-Tr 24/12-20A (240W) DC-DC Converter

The Victron Energy Orion-Tr 24/12-20A (240W) is a high-efficiency, non-isolated DC-DC converter designed to convert a 24V nominal input voltage to a stable 12V output. With a continuous output current of 20A and 240W of power, it is ideal for automotive, marine, and off-grid applications where reliable voltage conversion is required. The unit features synchronous rectification for up to 92% efficiency, remote on/off capability, and comprehensive protection against output short circuits and over-temperature.

Advantages

High efficiency (92%) reduces power loss and heat generation. Compact, surface-mount design with screw terminals for easy installation. Remote on/off control allows integration with battery management systems. Robust protection features ensure long-term reliability.

Suitable for

• Automotive and RV electrical systems
• Marine and boat power distribution
• Off-grid solar and battery systems
• Industrial and telecom equipment

Key specifications

• Input voltage range: 18-35V DC (nominal 24V)
• Output voltage: 12V DC (adjustable 10-15V)
• Continuous output current: 20A
• Continuous output power: 240W
• Efficiency: 92%
• Protection: Output short circuit, over temperature
• Enclosure: IP43 (vertical installation)
• Connection: Screw terminals
• Mounting: Surface mount (4 screw holes)
• Cooling: Convection
• No-load current: <20mA
• Certifications: CE, E-mark

Recommendations

For optimal performance, mount the converter vertically to ensure proper airflow and maintain the IP43 rating. Use appropriate gauge wiring for 20A continuous current. The remote on/off terminal can be connected to a switch or battery management system for efficient power control.
