Surveillance Camera Hikvision DS-7716NXI-I4/S(E)

The Hikvision DS-7716NXI-I4/S(E) is a 16-channel network video recorder designed for professional IP video surveillance systems. It captures and processes video at resolutions up to 3840 x 2160 pixels and supports simultaneous playback of up to 16 channels. The unit accepts SATA hard drives and provides a maximum internal storage capacity of 14 TB. With gigabit Ethernet support and a compact 1.5U rack height, the recorder is intended for small to medium sized installations requiring reliable continuous recording and centralized management of multiple IP cameras.

Advantages

This recorder combines high-resolution video support with multi-channel simultaneous playback, enabling effective review and monitoring of multiple camera streams. The SATA HDD interfaces allow use of standard surveillance drives up to the device’s maximum capacity, while Ethernet speeds of 10/100/1000 Mbit/s ensure compatibility with various network infrastructures. The unit’s low power consumption and compact 1.5U rack design reduce space and energy requirements in server cabinets. The device is supplied in a black finish and weighs approximately 3.6 kg, making it straightforward to install and integrate into existing systems.

Suitable for

• Small to medium business CCTV networks requiring up to 16 IP camera inputs
• Retail stores, offices or branch locations needing local centralized recording
• Monitoring rooms where simultaneous playback of multiple streams is necessary
• Environments where rack-mountable, energy-efficient recorders are preferred

Key specifications

• Video inputs: 16 network channels
• Maximum recording resolution: 3840 x 2160 pixels
• Simultaneous playback: up to 16 channels
• Maximum internal storage: 14 TB (SATA HDDs)
• Network interfaces: Ethernet 10/100/1000 Mbit/s
• Form factor: 1.5U rack-mountable
• Power consumption: 30 W
• AC input voltage and frequency: 100–240 V, 50–60 Hz
• Product colour: Black
• Weight: approximately 3.6 kg

How to use

Install compatible SATA surveillance hard drives up to the maximum supported capacity and secure the recorder in a suitable 1.5U rack space. Connect IP cameras to the local network and configure camera channels via the recorder’s management interface or client software. Ensure a stable Ethernet connection at 10/100/1000 Mbit/s and set recording schedules, motion detection or continuous recording as required. Connect the recorder to AC power (100–240 V, 50–60 Hz) and verify system time, user access permissions and network settings before placing the system into regular operation.

Recommendations

For reliable long-term recording, use enterprise-class surveillance SATA HDDs and configure regular backup and maintenance routines. Place the recorder in a well-ventilated rack space and ensure steady network bandwidth to avoid dropped frames during peak recording or playback sessions.
