Shuttle XPC slim Barebone XB860G2 - S1851, Intel H860, 1xDP, 2xHDMI, 2 PCIe Slots (1x 16X & 1x X1), 2x Intel LAN (1G + 2.5G), 8x USB, 3x M.2, 24/7 permanent operation

Shuttle XPC slim Barebone XB860G2 - S1851, Intel H860, 1xDP, 2xHDMI, 2 PCIe Slots (1x 16X & 1x X1), 2x Intel LAN (1G + 2.5G), 8x USB, 3x M.2, 24/7 permanent operation
Shuttle XPC slim Barebone XB860G2 - S1851, Intel H860, 1xDP, 2xHDMI, 2 PCIe Slots (1x 16X & 1x X1), 2x Intel LAN (1G + 2.5G), 8x USB, 3x M.2, 24/7 permanent operation
Shuttle XPC slim Barebone XB860G2 - S1851, Intel H860, 1xDP, 2xHDMI, 2 PCIe Slots (1x 16X & 1x X1), 2x Intel LAN (1G + 2.5G), 8x USB, 3x M.2, 24/7 permanent operation
Shuttle XPC slim Barebone XB860G2 - S1851, Intel H860, 1xDP, 2xHDMI, 2 PCIe Slots (1x 16X & 1x X1), 2x Intel LAN (1G + 2.5G), 8x USB, 3x M.2, 24/7 permanent operation
Shuttle XPC slim Barebone XB860G2 - S1851, Intel H860, 1xDP, 2xHDMI, 2 PCIe Slots (1x 16X & 1x X1), 2x Intel LAN (1G + 2.5G), 8x USB, 3x M.2, 24/7 permanent operation
Shuttle XPC slim Barebone XB860G2 - S1851, Intel H860, 1xDP, 2xHDMI, 2 PCIe Slots (1x 16X & 1x X1), 2x Intel LAN (1G + 2.5G), 8x USB, 3x M.2, 24/7 permanent operation
Shuttle XPC slim Barebone XB860G2 - S1851, Intel H860, 1xDP, 2xHDMI, 2 PCIe Slots (1x 16X & 1x X1), 2x Intel LAN (1G + 2.5G), 8x USB, 3x M.2, 24/7 permanent operation
Shuttle XPC slim Barebone XB860G2 - S1851, Intel H860, 1xDP, 2xHDMI, 2 PCIe Slots (1x 16X & 1x X1), 2x Intel LAN (1G + 2.5G), 8x USB, 3x M.2, 24/7 permanent operation
Shuttle XPC slim Barebone XB860G2 - S1851, Intel H860, 1xDP, 2xHDMI, 2 PCIe Slots (1x 16X & 1x X1), 2x Intel LAN (1G + 2.5G), 8x USB, 3x M.2, 24/7 permanent operation
Shuttle XPC slim Barebone XB860G2 - S1851, Intel H860, 1xDP, 2xHDMI, 2 PCIe Slots (1x 16X & 1x X1), 2x Intel LAN (1G + 2.5G), 8x USB, 3x M.2, 24/7 permanent operation
Shuttle XPC slim Barebone XB860G2 - S1851, Intel H860, 1xDP, 2xHDMI, 2 PCIe Slots (1x 16X & 1x X1), 2x Intel LAN (1G + 2.5G), 8x USB, 3x M.2, 24/7 permanent operation
Shuttle XPC slim Barebone XB860G2 - S1851, Intel H860, 1xDP, 2xHDMI, 2 PCIe Slots (1x 16X & 1x X1), 2x Intel LAN (1G + 2.5G), 8x USB, 3x M.2, 24/7 permanent operation
R7,272
The Shuttle XPC slim Barebone XB860G2 is a 4.5-litre PC with two slots for PCI-Express expansion cards. Together with a powerful socket LGA1851 Intel Core Ultra 2xx desktop processor (code name "Arrow Lake-S"), this platform is perfectly suited for many professional applications where performance, f... Read More
Stock 2 Code 2262573 Brand SHUTTLE Model XB860G2 Warranty 2 Years

Shipping & Returns

Estimated delivery Friday, October 9
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival
The Shuttle XPC slim Barebone XB860G2 is a 4.5-litre PC with two slots for PCI-Express expansion cards. Together with a powerful socket LGA1851 Intel Core Ultra 2xx desktop processor (code name "Arrow Lake-S"), this platform is perfectly suited for many professional applications where performance, flexibility and a compact form factor matter. You can install e.g. a multiport graphics card, a video capture card or I/O card to set up a mini PC for applications such as video wall presentations, graphics workstations, media capturing, surveillance, POS, POI as well as network and industrial applications. Even mid-range gaming is possible.

Shuttle XPC slim Barebone XB860G2 - S1851, Intel H860, 1xDP, 2xHDMI, 2 PCIe Slots (1x 16X & 1x X1), 2x Intel LAN (1G + 2.5G), 8x USB, 3x M.2, 24/7 permanent operation. Chassis type: 3.5L sized PC, Product type: PC barebone. Motherboard chipset: Intel B860, Processor socket: LGA 1851 (Socket V1), BIOS type: UEFI AMI. Supported memory types: DDR5-SDRAM, Number of memory slots: 2, Maximum internal memory: 96 GB. Supported storage drive types: SSD, Storage drive interface: PCI Express. Ethernet LAN (RJ-45) ports: 2. Cooling type: Active. Power supply: 180 W

Key Highlights
  • 3.5L sized PC Black
  • 2 SO-DIMM Maximum internal memory: 96 GB DDR5-SDRAM
  • SSD M.2
  • On-board graphics card
  • Ethernet LAN
Specifications
AC adapter included
Yes
AC adapter output current
9.23 A
AC adapter output voltage
19.5 V
AC input frequency
50/60 Hz
AC input voltage
100 - 240 V
Audio chip
Realtek ALC888S
BIOS type
UEFI AMI
Built-in processor
No
Built-in speaker(s)
No
Cable lock slot
Yes
Cable lock slot type
Kensington
Chassis type
3.5L sized PC
Compliance certificates
UKCA, CE, Federal Communications Commission (FCC), BSMI, RCM, VCCI, RoHS
Cooling type
Active
DC-in jack
Yes
Depth
200 mm
DisplayPort version
1.4a
DisplayPorts quantity
1
Drivers included
Yes
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
2
Harmonized System (HS) code
84733080
HDMI ports quantity
2
HDMI version
2.0/2.1
Headphone outputs
1
Height
72.5 mm
Internal memory installed
No
LAN controller
Intel I226-LM, Intel® I219-LM
LED indicators
HDD, Power
Maximum internal memory
96 GB
Memory channels
Dual-channel
Memory slots type
SO-DIMM
Memory voltage
1.1 V
Microphone in
Yes
Motherboard chipset
Intel B860
Motherboard form factor
mini ITX
Non-ECC
Yes
Number of memory slots
2
Number of power supply units
1
Number of processors supported
1
Number of storage drives supported
3
NVMe
Yes
On-board graphics card
Yes
Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
0 - 50 °C
Package weight
3.2 kg
Panel mounting interface
75 x 75,100 x 100 mm
Power cord included
Yes
Power supply
180 W
Power supply type
External AC adapter
Processor socket
LGA 1851 (Socket V1)
Product colour
Black
Product type
PC barebone
Quick start guide
Yes
SSD form factor
M.2
Storage drive interface
PCI Express
Storage drive sizes supported
M.2
Storage drives installed
No
Supported memory clock speeds
5600 MHz
Supported memory types
DDR5-SDRAM
Supported storage drive types
SSD
Sustainability certificates
ErP, ENERGY STAR
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
USB 2.0 ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
VESA mounting
Yes
VGA (D-Sub) ports quantity
0
Weight
1.9 kg
Wi-Fi
No
Width
238 mm

Leaflet

Open Leaflet

Document

Open Document

Manual

Open Manual
