ShiverPeaks F-Doppelbuchse 85300-SET5 — F-type dual socket, up to 5-port connectivity

The ShiverPeaks F-Doppelbuchse 85300-SET5 provides two F-type female connectors integrated into a single outlet module and supports up to five-port connectivity in structured RF/coaxial setups. Designed for distribution of television, satellite and cable signals, this wall-mountable dual socket enables tidy routing of coaxial cables and simplifies connecting multiple devices within residential or small commercial installations.

Advantages

The dual F-type configuration allows two separate coaxial terminations in one module, reducing wall clutter and simplifying outlet layouts when multiple signal paths are required. Compatibility with standard F-connectors ensures easy installation with common coaxial cables and accessories. The modular design supports organized cabling and can be combined with other outlets in structured installation environments.

Suitable for

• TV signal distribution in living rooms, bedrooms and media rooms
• Satellite receiver connections in residential and small commercial setups
• Cable television and set-top box installations
• Structured cabling panels and wall outlet arrays requiring multiple F-connections
• Upgrading single outlets to provide additional device connections

Key specifications

• Connector type: F-type female (dual)
• Maximum connectivity: up to 5 ports supported in the overall installation
• Intended signals: RF/coaxial for TV, satellite and cable
• Mounting: wall outlet / module format for structured installation
• Cable compatibility: standard coaxial cable with F-connectors

How to use

Install the dual F-type outlet into a compatible wall module or faceplate following standard low-voltage installation procedures. Terminate incoming and outgoing coaxial cables with compatible F-connectors and attach them to the female sockets. Ensure connections are tightened to maintain signal integrity and verify continuity and signal levels with appropriate test equipment. Combine this module with additional outlets to reach the intended maximum of five F-connections within the overall distribution system.

Recommendations

For best performance, use quality coaxial cable with properly crimped or compression F-connectors, avoid sharp bends or kinks in the cable run, and minimize the number of unnecessary splitters. Verify signal levels after installation and, if required, use amplifiers or line equalizers to compensate for long cable runs or multiple distribution points.
