SFP transceiver BlueOptics SPP-10S-LR-EDFC-BO 10000 Mbit/s

The BlueOptics SPP-10S-LR-EDFC-BO is an SFP+ transceiver module designed for single-mode fiber optic links with a maximum data transfer rate of 10000 Mbit/s. Housed in a robust silver metal casing and weighing approximately 20 g, the module follows MSA-compliant SFP+ mechanical and electrical specifications and uses an LC duplex optical connector for simultaneous transmit and receive on separate fibers. The transceiver is intended for high-speed Ethernet and similar optical networking applications and offers a high MTBF for long-term operation.

Advantages

The transceiver provides 10G-capable performance in a compact SFP+ form factor and is compatible with standard LC duplex single-mode fiber connections. Its metal housing ensures mechanical durability and thermal stability during continuous operation. With a specified mean time between failures of 1,000,000 hours, the module is suitable for deployments that require long operational lifetimes and reduced maintenance intervals. Lightweight and easy to handle, it can be installed or replaced without specialized tools.

Suitable for

• 10 Gigabit Ethernet links over single-mode fiber
• Long-distance uplinks and inter-switch connections (up to typical LR ranges)
• Enterprise switches, routers and storage networking equipment that accept MSA-compliant SFP+ modules
• Data center and telecom aggregation links

Key specifications

• Interface type: SFP+ form factor
• Maximum data transfer rate: 10000 Mbit/s
• Optical connector: LC duplex (single-mode fiber)
• Transceiver wavelength: 1310 nm (Tx and Rx)
• Housing: metal, silver colour
• Weight: approx. 0.02 kg
• Mean time between failures (MTBF): 1,000,000 hours

How to use

Insert the BlueOptics SFP+ transceiver into a compatible SFP+ slot on your switch, router or other networking device while the host port is powered down or following the host vendor's hot-swap procedure. Connect LC duplex single-mode fiber patch cords to the module's LC ports, observing correct Tx/Rx orientation. Ensure the host device firmware or software supports MSA-compliant SFP+ modules and, if available, enable digital diagnostics monitoring (DDM/DOM) to view real-time parameters such as optical power and temperature. After installation, verify link status and data throughput on the host device.

Recommendations

Use high-quality single-mode LC duplex patch cords and appropriate patch panels to achieve optimal link performance. Verify compatibility with the specific network hardware vendor and ensure that DDM/DOM support is enabled on both the module and host equipment for remote diagnostics. Avoid excessive bending of fiber cables and follow ESD precautions when handling the transceiver to preserve long-term reliability.
