PULSAR AWZ517 Relay Module, SPDT, 10-30V DC, 1A

The PULSAR AWZ517 is a versatile relay module designed to provide reliable switching for a wide array of control and automation applications. It supports an input voltage range of 10-30V DC, making it compatible with common power supplies found in industrial and commercial environments.

Advantages

This module features a single SPDT relay with both normally open and normally closed contacts, offering flexibility in circuit design. The built-in LED indicator provides instant visual feedback on relay status, simplifying troubleshooting. Compact and easy to install, it can be mounted using either the integrated mounting holes or adhesive tape, allowing for seamless integration into existing setups. Screw terminals ensure secure and maintenance-free connections.

Suitable for

• Industrial control panels
• Building automation and HVAC systems
• Security and alarm systems
• Access control systems
• Embedded control projects

Key specifications

• Model: AWZ517
• Number of channels: 1
• Relay type: SPDT
• Contact configuration: NO/NC
• Input voltage range: 10-30V DC
• Maximum switching voltage: 30V DC / 50V AC
• Maximum switching current: 1A
• Maximum switching power: 30W (DC) / 50VA (AC)
• Current consumption: 25mA @12V DC, 15mA @24V DC
• Operating temperature: -10°C to +50°C
• Connection: Screw terminals
• Mounting: Mounting holes or adhesive tape
• Status indicator: LED

Recommendations

Always verify that the connected load does not exceed the module's maximum ratings. Use proper electrical protection and adhere to applicable safety standards during installation.
