Power Adapter MEAN WELL DPAN02B-05 2W 5V Input 18-36V

The MEAN WELL DPAN02B-05 is a compact PCB-mount DC-DC converter designed for systems with an input range of 18–36 V DC. In a SIP through-hole package it provides a regulated single output of 5 V at up to 2 W total power and meets RoHS requirements for environmental compliance.

Advantages

Compact SIP through-hole design for easy PCB mounting, a wide input voltage window that supports 18–36 V DC sources, and a stable 5 V output suitable for low-power electronics. RoHS compliance reduces environmental impact and supports regulatory requirements.

Suitable for

• Embedded electronic modules requiring a stable 5 V rail
• Industrial control circuits with 18–36 V supply buses
• Prototyping and small PCB assemblies where a SIP footprint is preferred

Key specifications

• Brand: mean well
• Model / MPN: DPAN02B-05
• Input voltage: 18–36 V DC
• Output: 5 V DC, up to 2 W
• Package: SIP through-hole
• Compliance: RoHS
• EAN: 4021087046435

How to use

Mount the DPAN02B-05 into the designated SIP through-hole footprint on the PCB and solder according to standard through-hole practices. Connect the input to a DC source within 18–36 V and take the regulated 5 V output from the corresponding output pins. Observe polarity when wiring input and output connections and ensure adequate spacing for heat dissipation in confined assemblies.

Recommendations

Use with input voltages maintained within the specified 18–36 V range, keep output load within the 2 W power limit, and provide proper PCB mounting and ventilation. Follow manufacturer datasheet for detailed thermal and application guidance.
